Product comparison · 2 solar panels

Sharp NU-JB395 solar panel vs Sharp NU-JC330 solar panel

Key differences

Rated power
- NU-JB395 solar panel:395 W
- NU-JC330 solar panel:330 W
Current at maximum power (Imp)
- NU-JB395 solar panel:9.62 A
- NU-JC330 solar panel:9.63 A
Maximum system voltage
- NU-JB395 solar panel:1500 V
- NU-JC330 solar panel:1000 V
Voltage at maximum power (Vmp)
- NU-JB395 solar panel:41.07 V
- NU-JC330 solar panel:34.27 V
Voltage at open-circuit (Voc)
- NU-JB395 solar panel:49.45 V
- NU-JC330 solar panel:41.32 V
Cell efficiency
- NU-JB395 solar panel:19.6%
- NU-JC330 solar panel:19.5%
Number of cells
- NU-JB395 solar panel:144
- NU-JC330 solar panel:120
Height
- NU-JB395 solar panel:2008 mm
- NU-JC330 solar panel:1684 mm

Differences highlightedShow differences only

Comparison of NU-JB395, NU-JC330
19 specifications	A Sharp NU-JB395 solar panel Model NU-JB395 View product	B Sharp NU-JC330 solar panel Model NU-JC330 View product
Power5 differ
Rated powerDiffers	395 W	330 W
Current	20 A	20 A
Current at maximum power (Imp)Differs	9.62 A	9.63 A
Maximum system voltageDiffers	1500 V	1000 V
Short-circuit current (Isc)	10.35 A	10.35 A
Voltage at maximum power (Vmp)Differs	41.07 V	34.27 V
Voltage at open-circuit (Voc)Differs	49.45 V	41.32 V
Features2 differ
Solar cell type	Monocrystalline silicon	Monocrystalline silicon
Connector typeKnown for one	Unknown — not stated by the source	MC4
Product colour	Black	Black
Housing material	Aluminium	Aluminium
International Protection (IP) code	IP68	IP68
Cell efficiencyDiffers	19.6%	19.5%
Number of cellsDiffers	144	120
Operational conditionsidentical
Operating temperature (T-T)	-40 - 85 °C	-40 - 85 °C
Weight & dimensions2 differ
Width	1002 mm	1002 mm
Depth	40 mm	40 mm
HeightDiffers	2008 mm	1684 mm
WeightDiffers	23.5 kg	19.5 kg

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
