Product comparison · 2 servers

NEC Express5800 120Eg, NL vs NEC Express5800 120Rh-2, NL/EN/FR

32specifications compared
19differ
13identical
8known for one product only

Key differences

Motherboard chipset
- Express5800 120Eg, NL:Intel® E7320
- Express5800 120Rh-2, NL/EN/FR:Intel® E7520
Internal memory
- Express5800 120Eg, NL:0.5 GB
- Express5800 120Rh-2, NL/EN/FR:1 GB
Internal memory type
- Express5800 120Eg, NL:DDR-SDRAM
- Express5800 120Rh-2, NL/EN/FR:DDR2-SDRAM
Memory slots
- Express5800 120Eg, NL:4x DIMM
- Express5800 120Rh-2, NL/EN/FR:8x DIMM
Maximum internal memory
- Express5800 120Eg, NL:8 GB
- Express5800 120Rh-2, NL/EN/FR:12 GB
HDD capacity
- Express5800 120Eg, NL:146 GB
- Express5800 120Rh-2, NL/EN/FR:73 GB
Maximum graphics card memory
- Express5800 120Eg, NL:8 MB
- Express5800 120Rh-2, NL/EN/FR:16 MB
Networking features
- Express5800 120Eg, NL:Gigabit Ethernet
- Express5800 120Rh-2, NL/EN/FR:2-ch. Gigabit Ethernet

Side by side

Differences highlightedShow differences only

Comparison of Express5800 120Eg, NL, Express5800 120Rh-2, NL/EN/FR
40 specifications	A NEC Express5800 120Eg, NL View product	B NEC Express5800 120Rh-2, NL/EN/FR View product
Processor1 differ
Processor family	Intel® Xeon®	Intel® Xeon®
Processor frequency	2.8 GHz	2.8 GHz
Processor cache	2 MB	2 MB
Motherboard chipsetDiffers	Intel® E7320	Intel® E7520
Number of processors installed	1	1
Processor cache type	L2	L2
Processor front side bus	800 MHz	800 MHz
Memory4 differ
Internal memoryDiffers	0.5 GB	1 GB
Internal memory typeDiffers	DDR-SDRAM	DDR2-SDRAM
Memory layout (slots x size)Known for one	2 x 0.5 GB	Unknown — not stated by the source
Memory slotsDiffers	4x DIMM	8x DIMM
Maximum internal memoryDiffers	8 GB	12 GB
Storage1 differ
HDD capacityDiffers	146 GB	73 GB
HDD interface	SCSI	SCSI
Hot-swap	Yes	Yes
Graphics1 differ
Maximum graphics card memoryDiffers	8 MB	16 MB
Network1 differ
Networking featuresDiffers	Gigabit Ethernet	2-ch. Gigabit Ethernet
Wake-on-LAN ready	Yes	Yes
Ports & interfaces4 differ
Ethernet LAN (RJ-45) portsDiffers	1	2
USB 2.0 ports quantityDiffers	2	4
PS/2 ports quantityDiffers	2	1
Serial ports quantity	2	2
VGA (D-Sub) ports quantity	1	1
Expansion slotsDiffers	1x PCI Expresss (X4) 2x PCI-X 64bit/66MHz 2x PCI 32bit/33MHz (5V)	3x PCI-X 64bit/66MHz 3x 64-bit/66-100MHz
Design1 differ
Chassis typeDiffers	Tower	Rack
Software2 differ
Compatible operating systemsDiffers	Windows SBS 2003 Standard Windows 2000 Server Windows Server 2003 RedHat Linux ES 2.1/3.0	Windows Server 2003 (Std / Ent) Windows 2000 Server / Advanced Server Red Hat Linux
Bundled softwareDiffers	ESMPRO Server Manager ExpressBuilder	ESMPRO Management Suite ExpressBuilder Configuration Software
Poweridentical
Power supplyKnown for one	600 W	Unknown — not stated by the source
Power supply typeKnown for one	Unknown — not stated by the source	HotSwap, PFC
Operational conditionsidentical
Operating temperature (T-T)	10 - 35 °C	10 - 35 °C
Operating relative humidity (H-H)	20 - 80%	20 - 80%
Weight & dimensions4 differ
WidthDiffers	453 mm	483 mm
DepthDiffers	292 mm	835 mm
HeightDiffers	683 mm	88 mm
WeightDiffers	25 kg	21 kg
Other featuresidentical
CD read speedKnown for one	48x	Unknown — not stated by the source
Security featuresKnown for one	2 level password	Unknown — not stated by the source
Storage drive controllerKnown for one	Unknown — not stated by the source	2-channel U320 SCSI + HostRAID
Power availabilityKnown for one	Unknown — not stated by the source	600 W
Certificatesidentical
CertificationKnown for one	Unknown — not stated by the source	UL, FCC, CE

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
