Product comparison · 2 security cameras

LogiLink WC0011 security camera vs LogiLink WC0014 security camera

26specifications compared
8differ
18identical
7known for one product only

Key differences

Minimum illumination
- WC0011 security camera:0 lx
- WC0014 security camera:1 lx
Sensor type
- WC0011 security camera:CMOS
- WC0014 security camera:CCD
Optical sensor size
- WC0011 security camera:25.4 / 3.6 mm (1 / 3.6")
- WC0014 security camera:25.4 / 4 mm (1 / 4")
Focal length range
- WC0011 security camera:0 - 3.6 mm
- WC0014 security camera:3.9 - 85.9 mm
Maximum resolution
- WC0011 security camera:738 x 480 pixels
- WC0014 security camera:768 x 494 pixels
Dimensions (WxDxH)
- WC0011 security camera:115.2 x 152.5 x 40.2 mm
- WC0014 security camera:0 x 145 x 184 mm
Power requirements
- WC0011 security camera:12V/ 1A
- WC0014 security camera:12 V/1.5 A

Side by side

Differences highlightedShow differences only

Comparison of WC0011, WC0014
33 specifications	A LogiLink WC0011 security camera Model WC0011 View product	B LogiLink WC0014 security camera Model WC0014 View product
Camera1 differ
Minimum illuminationDiffers	0 lx	1 lx
Lens viewing angle, horizontalKnown for one	80°	Unknown — not stated by the source
Lens viewing angle, verticalKnown for one	55.6°	Unknown — not stated by the source
Camera shutter speed	1/60 - 1/100000 s	1/60 - 1/100000 s
Tilt angle rangeKnown for one	Unknown — not stated by the source	0 - 90°
Pan rangeKnown for one	Unknown — not stated by the source	0 - 360°
Image sensor2 differ
Sensor typeDiffers	CMOS	CCD
Optical sensor sizeDiffers	25.4 / 3.6 mm (1 / 3.6")	25.4 / 4 mm (1 / 4")
Lens system1 differ
Focal length rangeDiffers	0 - 3.6 mm	3.9 - 85.9 mm
Video1 differ
Maximum resolutionDiffers	738 x 480 pixels	768 x 494 pixels
Video formats supported	MPEG4	MPEG4
Frame rate	30 fps	30 fps
Analog signal format system	NTSC, PAL	NTSC, PAL
Audioidentical
Built-in microphoneKnown for one	Yes	Unknown — not stated by the source
Networkidentical
Supported network protocols	DDNS, DHCP, NTP, TCP/IP, ICPM, SMTP, FTP, HTTP, RTP, RTSP	DDNS, DHCP, NTP, TCP/IP, ICPM, SMTP, FTP, HTTP, RTP, RTSP
Ports & interfacesidentical
Ethernet LAN (RJ-45) ports	1	1
Microphone in	Yes	Yes
Securityidentical
Video motion detection	Yes	Yes
Active tampering alarmKnown for one	Unknown — not stated by the source	Yes
Management featuresidentical
Web-based management	Yes	Yes
Poweridentical
Power source type	PoE	PoE
Power over Ethernet (PoE)	Yes	Yes
Operational conditionsidentical
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Operating relative humidity (H-H)	0 - 85%	0 - 85%
System requirementsidentical
Minimum RAM	256 MB	256 MB
Minimum processor	Pentium 4	Pentium 4
Weight & dimensionsidentical
WeightKnown for one	812 g	Unknown — not stated by the source
Other features3 differ
Compatible operating systemsDiffers	Windows 7/Vista/ME/XP/2000/98	Windows 7/XP/ Vista/2000/ME/98
Compliance industry standards	IEEE 802.3	IEEE 802.3
Data transfer rate	10 Mbit/s	10 Mbit/s
Dimensions (WxDxH)Differs	115.2 x 152.5 x 40.2 mm	0 x 145 x 184 mm
Networking features	Fast Ethernet	Fast Ethernet
Power requirementsDiffers	12V/ 1A	12 V/1.5 A

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
