Product comparison · 2 power supply units

VIDA AA-500-YY power supply unit vs VIDA AA-750-YY power supply unit

44specifications compared
8differ
36identical
9known for one product only

Key differences

Total power
- AA-500-YY power supply unit:500 W
- AA-750-YY power supply unit:750 W
Peak power
- AA-500-YY power supply unit:500 W
- AA-750-YY power supply unit:750 W
Max output current (+3.3V)
- AA-500-YY power supply unit:10 A
- AA-750-YY power supply unit:33 A
Max output current (+12V)
- AA-500-YY power supply unit:30 A
- AA-750-YY power supply unit:37 A
Max output current (+5V)
- AA-500-YY power supply unit:12 A
- AA-750-YY power supply unit:38 A
Max output current (+5Vsb)
- AA-500-YY power supply unit:2 A
- AA-750-YY power supply unit:2.5 A
Weight
- AA-500-YY power supply unit:1.17 kg
- AA-750-YY power supply unit:1.29 kg
Package weight
- AA-500-YY power supply unit:1.4 kg
- AA-750-YY power supply unit:1.5 kg

Side by side

Differences highlightedShow differences only

Comparison of AA-500-YY, AA-750-YY
53 specifications	A VIDA AA-500-YY power supply unit Model AA-500-YY View product	B VIDA AA-750-YY power supply unit Model AA-750-YY View product
Power6 differ
Total powerDiffers	500 W	750 W
Peak powerDiffers	500 W	750 W
AC input voltage	200 - 240 V	200 - 240 V
AC input frequency	50/60 Hz	50/60 Hz
Power Factor Correction (PFC) type	Passive	Passive
Max output current (+3.3V)Differs	10 A	33 A
Max output current (+12V)Differs	30 A	37 A
Max output current (+5V)Differs	12 A	38 A
Max output current (-12V)	0.5 A	0.5 A
Max output current (+5Vsb)Differs	2 A	2.5 A
Power protection features	Over power	Over power
Number of +12V rail(s)Known for one	1	Unknown — not stated by the source
Ports & interfacesidentical
Motherboard power connector	24-pin ATX	24-pin ATX
Motherboard power cable lengthKnown for one	Unknown — not stated by the source	55 cm
Number of PATA power connectorsKnown for one	Unknown — not stated by the source	1
Number of SATA power connectors	6	6
SATA power cable length	800 mm	800 mm
Number of SATA power cables	2	2
Peripheral (Molex) power connectors (4-pin)	1	1
EPS power connector (4+4 pin)	Yes	Yes
PCI Express power connectors (6+2 pin)Known for one	Unknown — not stated by the source	1
PCI Express power cable lengthKnown for one	Unknown — not stated by the source	61 cm
CPU power connector (4+4 pin)	Yes	Yes
CPU power cable length	58 cm	58 cm
Floppy disk drive connector	Yes	Yes
Number of EPS connectors	1	1
PCI Express connector	Yes	Yes
Cabling type	Non-Modular	Non-Modular
Peripheral (Molex) power cable lengthKnown for one	800,1000 mm	Unknown — not stated by the source
ATX Power connector (24-pin)Known for one	Yes	Unknown — not stated by the source
Performanceidentical
Purpose	PC	PC
Power supply unit (PSU) form factor	ATX	ATX
80 PLUS certification	No	No
ATX version	1.3	1.3
Bearing technologyKnown for one	Hydraulic	Unknown — not stated by the source
Designidentical
Product colour	Black	Black
Cooling type	Active	Active
Fan diameter	12 cm	12 cm
Number of fansKnown for one	Unknown — not stated by the source	1 fan(s)
Fan location	Front	Front
Illumination	No	No
On/off switch	Yes	Yes
Certificatesidentical
Compliance certificates	UKCA, CE, RoHS	UKCA, CE, RoHS
Weight & dimensions1 differ
Width	150 mm	150 mm
Depth	85 mm	85 mm
Height	140 mm	140 mm
WeightDiffers	1.17 kg	1.29 kg
Packaging data1 differ
Package width	195 mm	195 mm
Package depth	92 mm	92 mm
Package height	160 mm	160 mm
Package weightDiffers	1.4 kg	1.5 kg
Package type	Box	Box
Logistics dataidentical
Country of origin	China	China

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
