Product comparison · 2 power supply units

itek Alimentatore GF1000 EVO vs itek Alimentatore PF1200 EVO

Key differences

Total power
- Alimentatore GF1000 EVO:1000 W
- Alimentatore PF1200 EVO:1200 W
80 PLUS certification
- Alimentatore GF1000 EVO:80 PLUS Gold
- Alimentatore PF1200 EVO:80 PLUS Platinum
Weight
- Alimentatore GF1000 EVO:2.7 kg
- Alimentatore PF1200 EVO:3.17 kg
Package weight
- Alimentatore GF1000 EVO:3.1 kg
- Alimentatore PF1200 EVO:3.5 kg

Differences highlightedShow differences only

Comparison of Alimentatore GF1000 EVO, Alimentatore PF1200 EVO
28 specifications	A itek Alimentatore GF1000 EVO View product	B itek Alimentatore PF1200 EVO View product
Power2 differ
Total powerDiffers	1000 W	1200 W
AC input voltage	100 - 240 V	100 - 240 V
Power Factor Correction (PFC) type	Active	Active
Power protection featuresDiffers	Over current, Over power, Over voltage, Short circuit, Under voltage	Over power, Over voltage, Under voltage, Over current, Short circuit
Ports & interfacesidentical
Motherboard power connector	24-pin ATX	24-pin ATX
Motherboard power cable length	57 cm	57 cm
Number of SATA power connectors	9	9
SATA power cable length	150,530 mm	150,530 mm
Peripheral (Molex) power connectors (4-pin)	3	3
Peripheral (Molex) power cable lengthKnown for one	470 mm	Unknown — not stated by the source
PCI Express power connectors (6+2 pin)	2	2
Cabling type	Fully-Modular	Fully-Modular
Performance1 differ
Purpose	PC	PC
Power supply unit (PSU) form factor	ATX	ATX
80 PLUS certificationDiffers	80 PLUS Gold	80 PLUS Platinum
ATX version	2.31	2.31
Mean time between failures (MTBF)	100000 h	100000 h
Designidentical
Product colour	Black	Black
Cooling type	Active	Active
Fan diameter	12 cm	12 cm
Number of fans	1 fan(s)	1 fan(s)
On/off switch	Yes	Yes
Weight & dimensions1 differ
Width	187.8 mm	187.8 mm
Depth	145.7 mm	145.7 mm
Height	86 mm	86 mm
WeightDiffers	2.7 kg	3.17 kg
Packaging data1 differ
Package weightDiffers	3.1 kg	3.5 kg
Package type	Box	Box

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
