Product comparison · 2 power supply units

i-tec PS380W power supply unit vs i-tec PS700W power supply unit

14specifications compared
6differ
8identical
26known for one product only

Key differences

Total power
- PS380W power supply unit:380 W
- PS700W power supply unit:700 W
Peripheral (Molex) power connectors (4-pin)
- PS380W power supply unit:2
- PS700W power supply unit:4
Cabling type
- PS380W power supply unit:Non-Modular
- PS700W power supply unit:Semi-Modular
Product colour
- PS380W power supply unit:Grey
- PS700W power supply unit:Black
Certification
- PS380W power supply unit:CE, RoHS
- PS700W power supply unit:CE, TUV, WEEE, RoHS

Side by side

Differences highlightedShow differences only

Comparison of PS380W, PS700W
40 specifications	A i-tec PS380W power supply unit Model PS380W View product	B i-tec PS700W power supply unit Model PS700W View product
Power2 differ
Total powerDiffers	380 W	700 W
AC input frequency	50 Hz	50 Hz
Input current	8 A	8 A
Power Factor Correction (PFC) typeKnown for one	Passive	Unknown — not stated by the source
Combined power (+3.3V)Known for one	120 W	Unknown — not stated by the source
Combined power (+12V)Known for one	300 W	Unknown — not stated by the source
Combined power (+5V)Known for one	120 W	Unknown — not stated by the source
Combined power (-12V)Known for one	3.6 W	Unknown — not stated by the source
Combined power (+5Vsb)Known for one	12.5 W	Unknown — not stated by the source
Max output current (+3.3V)Known for one	24 A	Unknown — not stated by the source
Max output current (+12V)Known for one	17 A	Unknown — not stated by the source
Max output current (+5V)Known for one	15 A	Unknown — not stated by the source
Max output current (-12V)Known for one	0.3 A	Unknown — not stated by the source
Max output current (+5Vsb)Known for one	2 A	Unknown — not stated by the source
Power protection featuresDiffers	Over power, Over voltage, Short circuit	Over current, Over power, Over voltage, Short circuit, Overload
AC input voltageKnown for one	Unknown — not stated by the source	230 V
Ports & interfaces2 differ
Motherboard power connectorKnown for one	20+4 pin ATX	Unknown — not stated by the source
Number of SATA power connectors	4	4
Peripheral (Molex) power connectors (4-pin)Differs	2	4
EPS power connector (8-pin)	Yes	Yes
PCI Express power connectors (6-pin)	1	1
Floppy drive power connector	1	1
Cabling typeDiffers	Non-Modular	Semi-Modular
PCI Express power connectors (8-pin)Known for one	Unknown — not stated by the source	1
CPU power connector (4+4 pin)Known for one	Unknown — not stated by the source	Yes
ATX power connector (20+4 pin)Known for one	Unknown — not stated by the source	Yes
Performanceidentical
PurposeKnown for one	PC	Unknown — not stated by the source
Power supply unit (PSU) form factor	ATX	ATX
ATX versionKnown for one	2.2	Unknown — not stated by the source
Design1 differ
Product colourDiffers	Grey	Black
Fan diameter	12 cm	12 cm
Number of fansKnown for one	1 fan(s)	Unknown — not stated by the source
Fan locationKnown for one	Top	Unknown — not stated by the source
LED indicatorsKnown for one	No	Unknown — not stated by the source
Certificates1 differ
CertificationDiffers	CE, RoHS	CE, TUV, WEEE, RoHS
Other featuresidentical
Output voltage noteKnown for one	3.3V, 5V, +12V1, +12V2, -12V, +5Vsb	Unknown — not stated by the source
Power over Ethernet (PoE)Known for one	No	Unknown — not stated by the source
Power supply typeKnown for one	AC/DC	Unknown — not stated by the source
Redundant power supply (RPS) supportKnown for one	No	Unknown — not stated by the source
Power requirementsKnown for one	Unknown — not stated by the source	230V, 50Hz

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
