Product comparison · 2 power supply units

Hiditec BZX750 power supply unit vs Hiditec BZX850 power supply unit

38specifications compared
7differ
31identical
0known for one product only

Key differences

Total power
- BZX750 power supply unit:750 W
- BZX850 power supply unit:850 W
Max output current (+3.3V)
- BZX750 power supply unit:25 A
- BZX850 power supply unit:20 A
Max output current (+12V)
- BZX750 power supply unit:62 A
- BZX850 power supply unit:70 A
Max output current (+5V)
- BZX750 power supply unit:25 A
- BZX850 power supply unit:20 A
Max output current (-12V)
- BZX750 power supply unit:0.5 A
- BZX850 power supply unit:0.3 A
Max output current (+5Vsb)
- BZX750 power supply unit:3 A
- BZX850 power supply unit:2.5 A
Depth
- BZX750 power supply unit:85 mm
- BZX850 power supply unit:86 mm

Side by side

Differences highlightedShow differences only

Comparison of BZX750, BZX850
38 specifications	A Hiditec BZX750 power supply unit Model BZX750 View product	B Hiditec BZX850 power supply unit Model BZX850 View product
Power6 differ
Total powerDiffers	750 W	850 W
AC input voltage	230 V	230 V
AC input frequency	50 - 60 Hz	50 - 60 Hz
Power Factor Correction (PFC) type	Active	Active
Max output current (+3.3V)Differs	25 A	20 A
Max output current (+12V)Differs	62 A	70 A
Max output current (+5V)Differs	25 A	20 A
Max output current (-12V)Differs	0.5 A	0.3 A
Max output current (+5Vsb)Differs	3 A	2.5 A
Power protection features	Over power, Over voltage, Short circuit, Under voltage	Over power, Over voltage, Short circuit, Under voltage
Ports & interfacesidentical
Motherboard power connector	20+4 pin ATX	20+4 pin ATX
Motherboard power cable length	60 cm	60 cm
Number of SATA power connectors	5	5
SATA power cable length	600 mm	600 mm
Peripheral (Molex) power connectors (4-pin)	2	2
Peripheral (Molex) power cable length	600 mm	600 mm
PCI Express power connectors (6-pin)	2	2
PCI Express power connectors (6+2 pin)	2	2
PCI Express power cable length	60 cm	60 cm
CPU power cable length	60 cm	60 cm
Floppy disk drive cable length	55 cm	55 cm
Floppy disk drive connector	Yes	Yes
Floppy drive power connector	1	1
Cabling type	Semi-Modular	Semi-Modular
Performanceidentical
Purpose	PC	PC
Power supply unit (PSU) form factor	ATX	ATX
80 PLUS certification	80 PLUS Bronze	80 PLUS Bronze
ATX version	2.4	2.4
Designidentical
Product colour	Black	Black
Cooling type	Active	Active
Fan diameter	14 cm	14 cm
Number of fans	1 fan(s)	1 fan(s)
Certificatesidentical
Compliance certificates	CE, RoHS	CE, RoHS
Weight & dimensions1 differ
Width	150 mm	150 mm
DepthDiffers	85 mm	86 mm
Height	160 mm	160 mm
Weight	1.75 kg	1.75 kg
Technical detailsidentical
Sustainability compliance	Yes	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
