Product comparison · 2 power distribution units (pdus)

Vertiv Geist UR30002L vs Vertiv Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black

17specifications compared
10differ
7identical
15known for one product only

Key differences

PDU types
- Geist UR30002L:Monitored
- Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black:Switched
AC outlets quantity
- Geist UR30002L:24 AC outlet(s)
- Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black:48 AC outlet(s)
Serial ports quantity
- Geist UR30002L:2
- Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black:1
Ethernet LAN (RJ-45) ports
- Geist UR30002L:2
- Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black:1
Nominal input voltage
- Geist UR30002L:100-240 V
- Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black:200-240 V
AC input frequency
- Geist UR30002L:50 - 60 Hz
- Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black:50/60 Hz
Maximum current
- Geist UR30002L:20 A
- Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black:50 A
Width
- Geist UR30002L:1683 mm
- Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black:94 mm

Side by side

Differences highlightedShow differences only

Comparison of Geist UR30002L, MNU3EHW1-48MI18-5CS15A0A10-S-A
32 specifications	A Vertiv Geist UR30002L View product	B Vertiv Geist MNU3EHW1-48MI18-5CS15A0A10-S-A power distribution unit (PDU) 48 AC outlet(s) 0U Black Model MNU3EHW1-48MI18-5CS15A0A10-S-A View product
Design1 differ
PDU typesDiffers	Monitored	Switched
Rack capacity	0U	0U
Product colour	Black	Black
MountingKnown for one	Unknown — not stated by the source	Vertical
DisplayKnown for one	Unknown — not stated by the source	LED
Ports & interfaces3 differ
AC outlets quantityDiffers	24 AC outlet(s)	48 AC outlet(s)
Power plugKnown for one	C20 coupler	Unknown — not stated by the source
AC outlet types	C13 coupler, C19 coupler	C13 coupler, C19 coupler
Serial ports quantityDiffers	2	1
Ethernet LAN (RJ-45) portsDiffers	2	1
USB ports quantity	1	1
Featuresidentical
Daisy chainKnown for one	Yes	Unknown — not stated by the source
Reset button	Yes	Yes
Colour-coded outletsKnown for one	Yes	Unknown — not stated by the source
LED indicatorsKnown for one	Unknown — not stated by the source	Yes
Cable lengthKnown for one	Unknown — not stated by the source	3 m
Management features1 differ
Monitoring	Current, Power, Voltage	Current, Power, Voltage
Supported network protocolsDiffers	DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+	DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+, Modbus TCP
Power3 differ
Nominal input voltageDiffers	100-240 V	200-240 V
AC input frequencyDiffers	50 - 60 Hz	50/60 Hz
Maximum currentDiffers	20 A	50 A
Nominal output voltageKnown for one	100-240 V	Unknown — not stated by the source
Maximum powerKnown for one	3600 W	Unknown — not stated by the source
Power protection featuresKnown for one	Unknown — not stated by the source	Over current
Certificatesidentical
Compliance certificatesKnown for one	RoHS	Unknown — not stated by the source
CertificationKnown for one	CE, FCC, EN 55032,EN 55024, IEC 60950-1, RCM, UL, c-UL	Unknown — not stated by the source
Weight & dimensions2 differ
WidthDiffers	1683 mm	94 mm
DepthDiffers	51 mm	1905 mm
Height	66 mm	66 mm
WeightKnown for one	8.16 kg	Unknown — not stated by the source
Operational conditionsidentical
Operating temperature (T-T)Known for one	Unknown — not stated by the source	0 - 60 °C
Logistics dataidentical
Country of originKnown for one	Unknown — not stated by the source	United States

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
