Product comparison · 2 power distribution units (pdus)

Middle Atlantic PDU-02 power distribution unit (PDU) 2 AC outlet(s) Black vs Middle Atlantic PDU-16 power distribution unit (PDU) 16 AC outlet(s) Black

Key differences

AC outlets quantity
- PDU-02 power distribution unit (PDU) 2 AC outlet(s) Black:2 AC outlet(s)
- PDU-16 power distribution unit (PDU) 16 AC outlet(s) Black:16 AC outlet(s)
Width
- PDU-02 power distribution unit (PDU) 2 AC outlet(s) Black:44 mm
- PDU-16 power distribution unit (PDU) 16 AC outlet(s) Black:41.2 mm
Depth
- PDU-02 power distribution unit (PDU) 2 AC outlet(s) Black:180 mm
- PDU-16 power distribution unit (PDU) 16 AC outlet(s) Black:1768 mm
Height
- PDU-02 power distribution unit (PDU) 2 AC outlet(s) Black:118 mm
- PDU-16 power distribution unit (PDU) 16 AC outlet(s) Black:48 mm
Weight
- PDU-02 power distribution unit (PDU) 2 AC outlet(s) Black:660 g
- PDU-16 power distribution unit (PDU) 16 AC outlet(s) Black:1.78 kg

Differences highlightedShow differences only

Comparison of PDU-02, PDU-16
23 specifications	A Middle Atlantic PDU-02 power distribution unit (PDU) 2 AC outlet(s) Black Model PDU-02 View product	B Middle Atlantic PDU-16 power distribution unit (PDU) 16 AC outlet(s) Black Model PDU-16 View product
Designidentical
PDU types	Basic	Basic
Product colour	Black	Black
Ports & interfaces1 differ
AC outlets quantityDiffers	2 AC outlet(s)	16 AC outlet(s)
Featuresidentical
LED indicators	Activity, Link, Power, Status	Activity, Link, Power, Status
Management featuresidentical
Supported network protocols	SSL/TLS, SMTP, NTP, DDNS, Cloud, TCP/IP, HTTP (integrated web server)	SSL/TLS, SMTP, NTP, DDNS, Cloud, TCP/IP, HTTP (integrated web server)
Poweridentical
Nominal input voltage	120 V	120 V
AC input frequency	50-60 Hz	50-60 Hz
Maximum current	15 A	15 A
Nominal output voltage	120 V	120 V
Output voltage	140 V	140 V
Surge energy rating	120 J	120 J
Surge protection	Yes	Yes
Certificatesidentical
Compliance certificates	Federal Communications Commission (FCC), RoHS	Federal Communications Commission (FCC), RoHS
Certification	FCC, RoHS, UL, CAN/CSA	FCC, RoHS, UL, CAN/CSA
Sustainabilityidentical
Sustainability compliance	Yes	Yes
Operational conditionsidentical
Operating temperature (T-T)	32 - 104 °F	32 - 104 °F
Operating relative humidity (H-H)	0 - 95%	0 - 95%
Weight & dimensions4 differ
WidthDiffers	44 mm	41.2 mm
DepthDiffers	180 mm	1768 mm
HeightDiffers	118 mm	48 mm
WeightDiffers	660 g	1.78 kg
Packaging contentidentical
Manual	Yes	Yes
Logistics dataidentical
Warranty period	3 year(s)	3 year(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
