Product comparison · 2 pcs/workstations

Ernitec WD-IU5-8TB PC/workstation 225 vs Ernitec WD-IU5-8TB-IOT PC/workstation 225

71specifications compared
2differ
69identical
3known for one product only

Key differences

Operating system installed
- WD-IU5-8TB PC/workstation 225:Windows 11 Pro
- WD-IU5-8TB-IOT PC/workstation 225:Windows 11 IoT Enterprise
Operating system language
- WD-IU5-8TB PC/workstation 225:Multilingual
- WD-IU5-8TB-IOT PC/workstation 225:English

Side by side

Differences highlightedShow differences only

Comparison of WD-IU5-8TB, WD-IU5-8TB-IOT
74 specifications	A Ernitec WD-IU5-8TB PC/workstation 225 Model WD-IU5-8TB View product	B Ernitec WD-IU5-8TB-IOT PC/workstation 225 Model WD-IU5-8TB-IOT View product
Processoridentical
Processor manufacturer	Intel	Intel
Processor model	225	225
Processor cores	10	10
Processor threads	10	10
Processor frequency	4.9 GHz	4.9 GHz
Performance cores	6	6
Efficient cores	4	4
Performance-core Max Turbo Frequency	4.9 GHz	4.9 GHz
Efficient-core Max Turbo Frequency	4.4 GHz	4.4 GHz
Performance-core base frequency	3.3 GHz	3.3 GHz
Efficient-core base frequency	2.7 GHz	2.7 GHz
Processor cache	30 MB	30 MB
Processor cache type	Smart Cache	Smart Cache
Processor socket	LGA 1851 (Socket V1)	LGA 1851 (Socket V1)
Processor base power	65 W	65 W
Memoryidentical
Internal memory	16 GB	16 GB
Maximum internal memory	128 GB	128 GB
Internal memory type	DDR5-SDRAM	DDR5-SDRAM
Memory layout (slots x size)	1 x 16 GB	1 x 16 GB
Memory clock speed	5600 MHz	5600 MHz
ECCKnown for one	No	Unknown — not stated by the source
Memory channels	Dual-channel	Dual-channel
Supported memory types	DDR5-SDRAM	DDR5-SDRAM
Storageidentical
Total storage capacity	8.5 TB	8.5 TB
Number of HDDs installed	1	1
HDD capacity	8 TB	8 TB
HDD interface	SATA III	SATA III
HDD size	3.5"	3.5"
Total SSDs capacity	500 GB	500 GB
Number of SSDs installed	1	1
SSD interface	SATA III	SATA III
SSD form factor	2.5"	2.5"
Graphicsidentical
On-board GPU manufacturer	Intel	Intel
On-board graphics card family	Intel Arc Graphics	Intel Arc Graphics
On-board graphics card model	Intel Arc Graphics	Intel Arc Graphics
On-board graphics card 4K support	Yes	Yes
Graphics card family	Intel	Intel
Number of displays supported (on-board graphics)Known for one	Unknown — not stated by the source	2
Performanceidentical
Product type	Workstation	Workstation
Motherboard chipset	Intel H810	Intel H810
Motherboard form factor	micro ATX	micro ATX
BIOS memory size	256 Mbit	256 Mbit
BIOS type	UEFI AMI	UEFI AMI
Trusted Platform Module (TPM)	Yes	Yes
Trusted Platform Module (TPM) version	2.0	2.0
Networkidentical
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	1000 Mbit/s	1000 Mbit/s
Wake-on-LAN ready	Yes	Yes
Ethernet interface type	Gigabit Ethernet	Gigabit Ethernet
Ports & interfacesidentical
DisplayPorts quantity	1	1
DisplayPort version	1.4	1.4
HDMI ports quantity	1	1
HDMI version	2.1	2.1
Ethernet LAN (RJ-45) ports	2	2
Number of front USB ports	2	2
Number of rear USB ports	6	6
Poweridentical
Power supply	300 W	300 W
Designidentical
Number of 2.5" bays	1	1
Product colour	Black	Black
Form factor	Mini Tower / Desktop	Mini Tower / Desktop
Software2 differ
Operating system installedDiffers	Windows 11 Pro	Windows 11 IoT Enterprise
Operating system languageDiffers	Multilingual	English
Compatible operating systems	Windows 11	Windows 11
Displayidentical
Number of displays supportedKnown for one	2	Unknown — not stated by the source
Processor special featuresidentical
Processor ARK ID	241070	241070
Weight & dimensionsidentical
Width	210 mm	210 mm
Depth	430 mm	430 mm
Height	480 mm	480 mm
Weight	5 kg	5 kg
Packaging dataidentical
Package width	310 mm	310 mm
Package depth	540 mm	540 mm
Package height	530 mm	530 mm
Package weight	6 kg	6 kg
Packaging contentidentical
Power cord included	Yes	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
