Product comparison · 2 network transceiver modules

StarTech.com HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei vs StarTech.com MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM

31specifications compared
9differ
22identical
3known for one product only

Key differences

Maximum transfer distance
- HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei:10000 m
- MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM:100 m
Wavelength
- HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei:1310 nm
- MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM:850 nm
Networking standards
- HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei:IEEE 802.3cc
- MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM:IEEE 802.3by
Mean time between failures (MTBF)
- HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei:3292647 h
- MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM:4020594 h
Brand compatibility
- HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei:HPE
- MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM:MSA Compliant
Package width
- HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei:115 mm
- MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM:91 mm
Package depth
- HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei:94 mm
- MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM:114 mm
Package height
- HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei:32 mm
- MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM:33 mm

Side by side

Differences highlightedShow differences only

Comparison of JL486A-ST, SFP-25G-SR-S-M-ST
34 specifications	A StarTech.com HPE JL486A Compatible SFP28 Module, 25GBase-LR, 25Gbps Single Mode Fiber (SMF), 10km (6.2mi), LC Connector, 1310nm, MSA 25 Gigabit Optical Transcei Model JL486A-ST View product	B StarTech.com MSA-Compliant SFP-25G-SR-S SFP28 Module, 25Gbps Multimode Fiber (MMF), 100m (328ft), LC Connector, 850nm, 25 Gigabit Optical Transceiver w/ DDM/DOM Model SFP-25G-SR-S-M-ST View product
Performance3 differ
SFP transceiver type	Fiber optic	Fiber optic
Maximum data transfer rate	25780 Mbit/s	25780 Mbit/s
Interface type	SFP28	SFP28
Multi-mode fiber (MMF) supportedKnown for one	Unknown — not stated by the source	Yes
Fiber optic connector	LC	LC
SFP transceiver standardKnown for one	Unknown — not stated by the source	SR
Maximum transfer distanceDiffers	10000 m	100 m
WavelengthDiffers	1310 nm	850 nm
Networking standardsDiffers	IEEE 802.3cc	IEEE 802.3by
Fiber ethernet cabling technology	25GBASE	25GBASE
Duplex system	Full	Full
Digital Diagnostics Monitoring (DDM)	Yes	Yes
Single-mode fiber (SMF) supportedKnown for one	Yes	Unknown — not stated by the source
Features2 differ
Product colour	Silver	Silver
Mean time between failures (MTBF)Differs	3292647 h	4020594 h
Brand compatibilityDiffers	HPE	MSA Compliant
Poweridentical
Power consumption (typical)	1.2 W	1.2 W
Certificates1 differ
Compliance certificatesDiffers	Federal Communications Commission (FCC), CE, RoHS	CE, Federal Communications Commission (FCC), RoHS
Sustainabilityidentical
Sustainability compliance	Yes	Yes
Operational conditionsidentical
Operating temperature (T-T)	0 - 70 °C	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C	-40 - 85 °C
Operating relative humidity (H-H)	0 - 85%	0 - 85%
Weight & dimensionsidentical
Width	90 mm	90 mm
Depth	115 mm	115 mm
Height	31 mm	31 mm
Packaging contentidentical
Quantity per pack	1 pc(s)	1 pc(s)
Packaging data3 differ
Package widthDiffers	115 mm	91 mm
Package depthDiffers	94 mm	114 mm
Package heightDiffers	32 mm	33 mm
Package weight	200 g	200 g
Logistics dataidentical
Master (outer) case width	340 mm	340 mm
Master (outer) case length	420 mm	420 mm
Master (outer) case height	350 mm	350 mm
Products per master (outer) case	100 pc(s)	100 pc(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
