Product comparison · 2 network transceiver modules

LogiLink SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP vs LogiLink SFP006 network transceiver module Fiber optic 2500 Mbit/s mini-GBIC/SFP 1310 nm

Key differences

Maximum data transfer rate
- SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:1250 Mbit/s
- SFP006 network transceiver module Fiber optic 2500 Mbit/s mini-GBIC/SFP 1310 nm:2500 Mbit/s
SFP transceiver standard
- SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:BX-U
- SFP006 network transceiver module Fiber optic 2500 Mbit/s mini-GBIC/SFP 1310 nm:LX
Maximum transfer distance
- SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:20000 m
- SFP006 network transceiver module Fiber optic 2500 Mbit/s mini-GBIC/SFP 1310 nm:10000 m
Ethernet interface type
- SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:1.25 Gigabit Ethernet
- SFP006 network transceiver module Fiber optic 2500 Mbit/s mini-GBIC/SFP 1310 nm:2.5 Gigabit Ethernet

Differences highlightedShow differences only

Comparison of SFP003, SFP006
25 specifications	A LogiLink SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP Model SFP003 View product	B LogiLink SFP006 network transceiver module Fiber optic 2500 Mbit/s mini-GBIC/SFP 1310 nm Model SFP006 View product
Performance4 differ
SFP transceiver type	Fiber optic	Fiber optic
Maximum data transfer rateDiffers	1250 Mbit/s	2500 Mbit/s
Interface type	mini-GBIC/SFP	mini-GBIC/SFP
Single-mode fiber (SMF) supported	Yes	Yes
Fiber optic connector	LC	LC
SFP transceiver standardDiffers	BX-U	LX
Maximum transfer distanceDiffers	20000 m	10000 m
Tx wavelength (min)Known for one	1310 nm	Unknown — not stated by the source
Rx wavelength (min)Known for one	1550 nm	Unknown — not stated by the source
Ethernet LAN	Yes	Yes
Ethernet interface typeDiffers	1.25 Gigabit Ethernet	2.5 Gigabit Ethernet
Fiber ethernet cabling technology	1000BASE	1000BASE
Digital Diagnostics Monitoring (DDM)	Yes	Yes
WavelengthKnown for one	Unknown — not stated by the source	1310 nm
Featuresidentical
Product colour	Silver	Silver
Form factor	SFP	SFP
Plug and Play	Yes	Yes
Hot-Plug support	Yes	Yes
Hot-swap	Yes	Yes
Easy to install	Yes	Yes
Certificatesidentical
Compliance certificates	CE, UKCA	CE, UKCA
Weight & dimensionsidentical
Width	13.7 mm	13.7 mm
Depth	56.7 mm	56.7 mm
Height	12.8 mm	12.8 mm
Weight	20 g	20 g

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
