Product comparison · 2 network transceiver modules

LogiLink SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP vs LogiLink SFP004 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP

Key differences

SFP transceiver standard
- SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:BX-U
- SFP004 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:BX-D
Tx wavelength (min)
- SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:1310 nm
- SFP004 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:1550 nm
Rx wavelength (min)
- SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:1550 nm
- SFP004 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP:1310 nm

Differences highlightedShow differences only

Comparison of SFP003, SFP004
24 specifications	A LogiLink SFP003 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP Model SFP003 View product	B LogiLink SFP004 network transceiver module Fiber optic 1250 Mbit/s mini-GBIC/SFP Model SFP004 View product
Performance3 differ
SFP transceiver type	Fiber optic	Fiber optic
Maximum data transfer rate	1250 Mbit/s	1250 Mbit/s
Interface type	mini-GBIC/SFP	mini-GBIC/SFP
Single-mode fiber (SMF) supported	Yes	Yes
Fiber optic connector	LC	LC
SFP transceiver standardDiffers	BX-U	BX-D
Maximum transfer distance	20000 m	20000 m
Tx wavelength (min)Differs	1310 nm	1550 nm
Rx wavelength (min)Differs	1550 nm	1310 nm
Ethernet LAN	Yes	Yes
Ethernet interface type	1.25 Gigabit Ethernet	1.25 Gigabit Ethernet
Fiber ethernet cabling technology	1000BASE	1000BASE
Digital Diagnostics Monitoring (DDM)	Yes	Yes
Featuresidentical
Product colour	Silver	Silver
Form factor	SFP	SFP
Plug and Play	Yes	Yes
Hot-Plug support	Yes	Yes
Hot-swap	Yes	Yes
Easy to install	Yes	Yes
Certificatesidentical
Compliance certificates	CE, UKCA	CE, UKCA
Weight & dimensionsidentical
Width	13.7 mm	13.7 mm
Depth	56.7 mm	56.7 mm
Height	12.8 mm	12.8 mm
Weight	20 g	20 g

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
