Product comparison · 2 network transceiver modules

Intellinet Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 80 km (50 mi.), BiDi WDM (RX1490/TX1550), MSA-co vs Intellinet Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-U (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1550/TX1490), MSA-c

Add a product
  • 37specifications compared
  • 6differ
  • 31identical
  • 2known for one product only

Key differences

  • SFP transceiver standard
    • BX-D
    • BX-U
  • Maximum transfer distance
    • 80000 m
    • 120000 m
  • Tx wavelength (max)
    • 1550 nm
    • 1490 nm
  • Rx wavelength (max)
    • 1490 nm
    • 1550 nm
  • Tx power (min)
    • -5 dBmW
    • 0 dBmW
  • Tx power (max)
    • 0 dBmW
    • 5 dBmW

Side by side

Differences highlightedShow differences only
39 specifications
A

Intellinet

Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 80 km (50 mi.), BiDi WDM (RX1490/TX1550), MSA-co

Model 508629

View product
B

Intellinet

Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-U (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1550/TX1490), MSA-c

Model 508643

View product
Performance6 differ
SFP transceiver typeFiber opticFiber optic
Maximum data transfer rate1000 Mbit/s1000 Mbit/s
Interface typemini-GBIC/SFPmini-GBIC/SFP
Single-mode fiber (SMF) supportedYesYes
Fiber optic connectorLCLC
Fiber cable diameters supported (core/cladding)9/125 µm9/125 µm
SFP transceiver standardDiffersBX-DBX-U
Maximum transfer distanceDiffers80000 m120000 m
Tx wavelength (max)Differs1550 nm1490 nm
Rx wavelength (max)Differs1490 nm1550 nm
Tx power (min)Differs-5 dBmW0 dBmW
Tx power (max)Differs0 dBmW5 dBmW
Fiber ethernet cabling technology1000BASE1000BASE
Digital Diagnostics Monitoring (DDM)YesYes
Wavelength-division multiplexing (WDM)YesYes
Networking standardsKnown for oneIEEE 802.3z
Featuresidentical
Product colourSilverSilver
Housing materialKnown for oneMetal
Hot-Plug supportYesYes
Brand compatibilityMSA CompliantMSA Compliant
Poweridentical
Maximum voltage3.3 V3.3 V
Power consumption (typical)1 W1 W
Certificatesidentical
Compliance certificatesRoHS, Federal Communications Commission (FCC), National Defense Authorization Act (NDAA), UKCA, CERoHS, Federal Communications Commission (FCC), National Defense Authorization Act (NDAA), UKCA, CE
Sustainabilityidentical
Sustainability complianceYesYes
Operational conditionsidentical
Operating temperature (T-T)0 - 70 °C0 - 70 °C
Storage temperature (T-T)-40 - 85 °C-40 - 85 °C
Operating relative humidity (H-H)10 - 85%10 - 85%
Weight & dimensionsidentical
Width14 mm14 mm
Depth57 mm57 mm
Height12 mm12 mm
Weight20 g20 g
Packaging contentidentical
Quantity per pack1 pc(s)1 pc(s)
Packaging dataidentical
Package weight30 g30 g
Package typeBoxBox
Logistics dataidentical
Master (outer) case width200 mm200 mm
Master (outer) case length310 mm310 mm
Master (outer) case height250 mm250 mm
Master (outer) case gross weight2.6 kg2.6 kg
Products per master (outer) case48 pc(s)48 pc(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
