Product comparison · 2 network switches

Intellinet 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun vs Intellinet 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi

62specifications compared
16differ
46identical
0known for one product only

Key differences

Basic switching RJ-45 Ethernet ports quantity
- 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun:5
- 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi:8
2.5G Ethernet (copper) ports quantity
- 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun:5
- 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi:8
Switching capacity
- 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun:25 Gbit/s
- 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi:40 Gbit/s
Forwarding rate
- 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun:18.6 Mpps
- 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi:29.76 Mpps
Input current
- 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun:2 A
- 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi:2.22 A
Power consumption (max)
- 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun:58 W
- 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi:105 W
Total Power over Ethernet (PoE) budget
- 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun:55 W
- 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi:100 W
Width
- 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun:160 mm
- 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi:240 mm

Side by side

Differences highlightedShow differences only

Comparison of 561921-UK, 561938-UK
62 specifications	A Intellinet 5-Port 2.5G Ethernet PoE+ Switch Four PSE PoE+ Ports, 10/100/1000/2500 Mbps on all Ports, 55 W PoE Power Budget, Unmanaged, Desktop Format, Wall-moun Model 561921-UK View product	B Intellinet 8-Port 2.5G Ethernet PoE+ Switch Eight 10/100/1000/2500 Mbps PSE PoE+ Ports, 100 W PoE Power Budget, Unmanaged, Desktop Format, Wall-mount Option (wi Model 561938-UK View product
Management featuresidentical
Switch type	Unmanaged	Unmanaged
Ports & interfaces2 differ
Basic switching RJ-45 Ethernet ports quantityDiffers	5	8
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)	2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantityDiffers	5	8
Installed SFP modules quantity	0	0
Installed SFP+ modules quantity	0	0
Networkidentical
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
10G support	No	No
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T, 2500BASE-T	10BASE-T, 100BASE-TX, 1000BASE-T, 2500BASE-T
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6, Cat6a	Cat3, Cat4, Cat5, Cat5e, Cat6, Cat6a
Full duplex	Yes	Yes
Auto MDI/MDI-X	Yes	Yes
Auto-negotiation	Yes	Yes
Auto-sensing	Yes	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s	10,100,1000,2500 Mbit/s
Flow control support	Yes	Yes
MAC address auto-aging supported	Yes	Yes
MAC address auto-learning supported	Yes	Yes
Data transmission2 differ
MAC address table	16000 entries	16000 entries
Switching capacityDiffers	25 Gbit/s	40 Gbit/s
Forwarding rateDiffers	18.6 Mpps	29.76 Mpps
Store-and-forward	Yes	Yes
Jumbo frames support	Yes	Yes
Jumbo frames	12000	12000
Packet buffer memory	12 MB	12 MB
Designidentical
Rack mounting	No	No
Product colour	Black	Black
Housing material	Metal	Metal
LED indicators	Activity, Link, PoE, Power	Activity, Link, PoE, Power
Wall mountable	Yes	Yes
Power2 differ
Power source	AC/DC	AC/DC
Power supply included	Yes	Yes
AC input voltage	100 - 240 V	100 - 240 V
AC input frequency	50/60 Hz	50/60 Hz
Input currentDiffers	2 A	2.22 A
Power consumption (max)Differs	58 W	105 W
Power protection features	Over voltage, Overload, Short circuit	Over voltage, Overload, Short circuit
Power over Ethernet (PoE)1 differ
Power over Ethernet (PoE)	Yes	Yes
Power over Ethernet (PoE) power per port	30 W	30 W
Total Power over Ethernet (PoE) budgetDiffers	55 W	100 W
Other featuresidentical
Warranty period	3 year(s)	3 year(s)
Operational conditionsidentical
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%	10 - 90%
Storage relative humidity (H-H)	5 - 90%	5 - 90%
Weight & dimensions4 differ
WidthDiffers	160 mm	240 mm
DepthDiffers	110 mm	105 mm
HeightDiffers	26 mm	27 mm
WeightDiffers	500 g	690 g
Packaging contentidentical
Cables included	AC	AC
Manual	Yes	Yes
Packaging data3 differ
Package type	Box	Box
Package widthDiffers	132 mm	130 mm
Package depthDiffers	210 mm	256 mm
Package height	78 mm	78 mm
Package weightDiffers	1.1 kg	1.46 kg
Certificatesidentical
Certification	FCC Class A, CE, RoHS, UKCA, NDAA	FCC Class A, CE, RoHS, UKCA, NDAA
Logistics data2 differ
Master (outer) case width	283 mm	283 mm
Master (outer) case length	415 mm	415 mm
Master (outer) case heightDiffers	238 mm	282 mm
Master (outer) case gross weightDiffers	11.3 kg	15.6 kg
Products per master (outer) case	10 pc(s)	10 pc(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
