Product comparison · 2 network switches

Intellinet 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of vs Intellinet 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant

61specifications compared
13differ
48identical
1known for one product only

Key differences

Forwarding rate
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of:36.688 Mpps
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant:38.69 Mpps
Jumbo frames
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of:9200
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant:9216
Packet buffer memory
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of:0.5 MB
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant:4.1 MB
Operating temperature (T-T)
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of:0 - 45 °C
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant:0 - 40 °C
Depth
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of:208 mm
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant:207 mm
Package width
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of:295 mm
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant:315 mm
Package depth
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of:555 mm
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant:495 mm
Package height
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of:90 mm
- 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant:72 mm

Side by side

Differences highlightedShow differences only

Comparison of 561891-UK, 561907-UK
62 specifications	A Intellinet 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant, PoE Power Budget of Model 561891-UK View product	B Intellinet 24-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports IEEE 802.3at/af (PoE+/PoE) Compliant Model 561907-UK View product
Management featuresidentical
Switch typeKnown for one	Unknown — not stated by the source	Unmanaged
Ports & interfacesidentical
Basic switching RJ-45 Ethernet ports quantity	24	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0	0
Installed SFP+ modules quantity	0	0
SFP module slots quantity	2	2
Networkidentical
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support	No	No
Copper ethernet cabling technology	10BASE-TX, 10GBASE-T, 100BASE-TX	10BASE-TX, 10GBASE-T, 100BASE-TX
Cable types supported	Cat5e, Cat6	Cat5e, Cat6
Full duplex	Yes	Yes
Half duplex	Yes	Yes
Auto MDI/MDI-X	Yes	Yes
Flow control support	Yes	Yes
MAC address auto-aging supported	Yes	Yes
MAC address auto-learning supported	Yes	Yes
VLAN support	Yes	Yes
Data transmission3 differ
MAC address table	8000 entries	8000 entries
Switching capacity	52 Gbit/s	52 Gbit/s
Forwarding rateDiffers	36.688 Mpps	38.69 Mpps
Store-and-forward	Yes	Yes
Jumbo frames support	Yes	Yes
Jumbo framesDiffers	9200	9216
Packet buffer memoryDiffers	0.5 MB	4.1 MB
Designidentical
Rack mounting	Yes	Yes
Form factor	1U	1U
Product colour	Black	Black
Housing material	Metal	Metal
LED indicators	Activity, Link, PoE, Power	Activity, Link, PoE, Power
Number of fans	2 fan(s)	2 fan(s)
Poweridentical
Power source	AC	AC
AC input voltage	100 - 240 V	100 - 240 V
AC input frequency	50/60 Hz	50/60 Hz
Power consumption (max)	400 W	400 W
Power saving mode (EEE)	Yes	Yes
Power protection features	Over voltage, Overload, Short circuit	Over voltage, Overload, Short circuit
Power over Ethernet (PoE)identical
Power over Ethernet (PoE)	Yes	Yes
Power over Ethernet (PoE) power per port	30 W	30 W
Total Power over Ethernet (PoE) budget	370 W	370 W
Other featuresidentical
Warranty period	3 year(s)	3 year(s)
Operational conditions1 differ
Operating temperature (T-T)Differs	0 - 45 °C	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%	10 - 90%
Storage relative humidity (H-H)	5 - 90%	5 - 90%
Weight & dimensions1 differ
Width	440 mm	440 mm
DepthDiffers	208 mm	207 mm
Height	44 mm	44 mm
Weight	3.37 kg	3.37 kg
Packaging contentidentical
Cables included	AC	AC
Manual	Yes	Yes
Rack mount kit	Yes	Yes
Packaging data3 differ
Package type	Box	Box
Package widthDiffers	295 mm	315 mm
Package depthDiffers	555 mm	495 mm
Package heightDiffers	90 mm	72 mm
Package weight	3.87 kg	3.87 kg
Certificatesidentical
Certification	FCC, CE, RoHS, UKCA, NDAA	FCC, CE, RoHS, UKCA, NDAA
Logistics data5 differ
Master (outer) case widthDiffers	375 mm	390 mm
Master (outer) case lengthDiffers	575 mm	510 mm
Master (outer) case heightDiffers	320 mm	345 mm
Master (outer) case gross weightDiffers	16.6 kg	18 kg
Products per master (outer) caseDiffers	4 pc(s)	5 pc(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
