Product comparison · 2 network switches

Allied Telesis AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey vs InLine Network Switch 8-Port

15specifications compared
15differ
0identical
54known for one product only

Key differences

Basic switching RJ-45 Ethernet ports quantity
- AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey:16
- Network Switch 8-Port:8
MAC address table
- AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey:16000 entries
- Network Switch 8-Port:1000 entries
Product colour
- AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey:Grey
- Network Switch 8-Port:Black
Power over Ethernet (PoE)
- AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey:Yes
- Network Switch 8-Port:No
Operating temperature (T-T)
- AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey:0 - 50 °C
- Network Switch 8-Port:0 - 40 °C
Storage temperature (T-T)
- AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey:-20 - 60 °C
- Network Switch 8-Port:-40 - 70 °C
Operating relative humidity (H-H)
- AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey:5 - 90%
- Network Switch 8-Port:10 - 90%
Storage relative humidity (H-H)
- AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey:5 - 95%
- Network Switch 8-Port:5 - 90%

Side by side

Differences highlightedShow differences only

Comparison of AT-FS980M/18PS-50, 32308M
69 specifications	A Allied Telesis AT-FS980M/18PS-50 Managed Fast Ethernet (10/100) Power over Ethernet (PoE) Grey Model AT-FS980M/18PS-50 View product	B InLine Network Switch 8-Port Model 32308M View product
Management featuresidentical
Switch typeKnown for one	Managed	Unknown — not stated by the source
Quality of Service (QoS) supportKnown for one	Yes	Unknown — not stated by the source
Web-based managementKnown for one	Yes	Unknown — not stated by the source
Ports & interfaces2 differ
Basic switching RJ-45 Ethernet ports quantityDiffers	16	8
Basic switching RJ-45 Ethernet ports typeDiffers	Fast Ethernet (10/100)	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantityKnown for one	2	Unknown — not stated by the source
Installed SFP modules quantityKnown for one	0	Unknown — not stated by the source
Installed SFP+ modules quantityKnown for one	0	Unknown — not stated by the source
Console portKnown for one	RJ-45	Unknown — not stated by the source
Network1 differ
Networking standardsDiffers	IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.3z	IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technologyKnown for one	10BASE-T, 100BASE-T	Unknown — not stated by the source
Link aggregationKnown for one	Yes	Unknown — not stated by the source
Spanning tree protocolKnown for one	Yes	Unknown — not stated by the source
VLAN supportKnown for one	Yes	Unknown — not stated by the source
Virtual LAN featuresKnown for one	Private VLAN, Port-based VLAN	Unknown — not stated by the source
10G supportKnown for one	Unknown — not stated by the source	No
Cable types supportedKnown for one	Unknown — not stated by the source	Cat3, Cat4, Cat5, Cat5e
Full duplexKnown for one	Unknown — not stated by the source	Yes
Auto MDI/MDI-XKnown for one	Unknown — not stated by the source	Yes
Auto-negotiationKnown for one	Unknown — not stated by the source	Yes
Ethernet LAN data ratesKnown for one	Unknown — not stated by the source	10,100,1000 Mbit/s
Flow control supportKnown for one	Unknown — not stated by the source	Yes
MAC address auto-learning supportedKnown for one	Unknown — not stated by the source	Yes
Data transmission1 differ
MAC address tableDiffers	16000 entries	1000 entries
Switching capacityKnown for one	7.2 Gbit/s	Unknown — not stated by the source
ThroughputKnown for one	5.36 Mpps	Unknown — not stated by the source
Jumbo frames supportKnown for one	Yes	Unknown — not stated by the source
Jumbo framesKnown for one	10000	Unknown — not stated by the source
Forwarding rateKnown for one	Unknown — not stated by the source	0.1488 Mpps
Packet forwarding rate (10 Mbps)Known for one	Unknown — not stated by the source	14880 pps
Packet forwarding rate (100 Mbps)Known for one	Unknown — not stated by the source	148800 pps
Securityidentical
Access Control List (ACL)Known for one	Yes	Unknown — not stated by the source
IGMP snoopingKnown for one	Yes	Unknown — not stated by the source
BPDU filtering/protectionKnown for one	Yes	Unknown — not stated by the source
Multicast featuresidentical
Multicast supportKnown for one	Yes	Unknown — not stated by the source
Design1 differ
Rack mountingKnown for one	No	Unknown — not stated by the source
Product colourDiffers	Grey	Black
SafetyKnown for one	FCC, EN55022, CISPR22:2006, VCCI, C-Tick, UL 60950-1, C22.2 NO.60950-1, EN 60950-1, IEC60950-1, EN60950-1	Unknown — not stated by the source
LED indicatorsKnown for one	Unknown — not stated by the source	LAN, Power
Wall mountableKnown for one	Unknown — not stated by the source	Yes
Performanceidentical
Memory typeKnown for one	DDR2-SDRAM	Unknown — not stated by the source
Internal memoryKnown for one	128 MB	Unknown — not stated by the source
Flash memoryKnown for one	128 MB	Unknown — not stated by the source
Noise levelKnown for one	33 dB	Unknown — not stated by the source
Maximum data transfer rateKnown for one	Unknown — not stated by the source	1000 Mbit/s
Poweridentical
Power consumption (max)Known for one	24 W	Unknown — not stated by the source
Input currentKnown for one	Unknown — not stated by the source	0.5 A
Power over Ethernet (PoE)1 differ
Power over Ethernet (PoE)Differs	Yes	No
Power over Ethernet plus (PoE+) ports quantityKnown for one	16	Unknown — not stated by the source
Power over Ethernet (PoE) power per portKnown for one	16 W	Unknown — not stated by the source
Total Power over Ethernet (PoE) budgetKnown for one	250 W	Unknown — not stated by the source
Operational conditions4 differ
Operating temperature (T-T)Differs	0 - 50 °C	0 - 40 °C
Storage temperature (T-T)Differs	-20 - 60 °C	-40 - 70 °C
Operating relative humidity (H-H)Differs	5 - 90%	10 - 90%
Storage relative humidity (H-H)Differs	5 - 95%	5 - 90%
Heat dissipationKnown for one	1100 BTU/h	Unknown — not stated by the source
Weight & dimensions4 differ
WidthDiffers	440 mm	145 mm
DepthDiffers	257 mm	4.09 mm
HeightDiffers	43.2 mm	75 mm
WeightDiffers	3.6 kg	2.8 kg
Packaging data1 differ
Package weightDiffers	5.7 kg	303 g
Package widthKnown for one	Unknown — not stated by the source	60 mm
Package depthKnown for one	Unknown — not stated by the source	190 mm
Package heightKnown for one	Unknown — not stated by the source	140 mm
Certificatesidentical
CertificationKnown for one	CE, cULus, TUV, RoHS	Unknown — not stated by the source
Logistics dataidentical
Harmonized System (HS) codeKnown for one	85176990	Unknown — not stated by the source
Other featuresidentical
Dimensions (WxDxH)Known for one	Unknown — not stated by the source	145 x 4.09 x 75 mm
Ethernet LAN (RJ-45) portsKnown for one	Unknown — not stated by the source	8
Ethernet interface typeKnown for one	Unknown — not stated by the source	Fast Ethernet, Gigabit Ethernet

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
