Product comparison · 2 network extenders

StarTech.com 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA vs StarTech.com 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft)

30specifications compared
14differ
16identical
12known for one product only

Key differences

Type
- 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA:Network repeater
- 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft):Network transmitter
Certification
- 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA:CE, FCC, TAA, REACH
- 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft):CE, FCC
Power consumption (max)
- 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA:3.2 W
- 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft):3 W
Storage temperature (T-T)
- 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA:-10 - 85 °C
- 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft):-10 - 70 °C
Operating relative humidity (H-H)
- 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA:5 - 95%
- 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft):5 - 90%
Width
- 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA:69 mm
- 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft):77 mm
Depth
- 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA:94 mm
- 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft):140 mm
Height
- 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA:25 mm
- 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft):27 mm

Side by side

Differences highlightedShow differences only

Comparison of POEEXT1GAT, POEEXT2GAT
42 specifications	A StarTech.com 1-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) - TAA Model POEEXT1GAT View product	B StarTech.com 2-Port Gigabit PoE+ Extender - 802.3at and 802.3af - 100 m (330 ft) Model POEEXT2GAT View product
Performance1 differ
TypeDiffers	Network repeater	Network transmitter
Maximum transfer distance	100 m	100 m
Data transfer rate	2000 Mbit/s	2000 Mbit/s
Auto MDIX IEEE	Yes	Yes
Auto-negotiation	Yes	Yes
Duplex system	Full, Half	Full, Half
Jumbo frames support	No	No
Plug and Play	Yes	Yes
Mean time between failures (MTBF)	50000 h	50000 h
Flow control supportKnown for one	Unknown — not stated by the source	Yes
Network1 differ
Cabling technology	10/100/1000Base-T(X)	10/100/1000Base-T(X)
Networking standardsDiffers	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ports & interfacesidentical
Power over Ethernet (PoE) ports quantityKnown for one	2	Unknown — not stated by the source
RJ-45 ports quantity (transmitter)Known for one	Unknown — not stated by the source	2
RJ-45 ports quantity (receiver)Known for one	Unknown — not stated by the source	1
Design1 differ
Product colour	Black	Black
Housing material	Steel	Steel
LED indicators	Activity, Link, PoE	Activity, Link, PoE
CertificationDiffers	CE, FCC, TAA, REACH	CE, FCC
Power1 differ
AC input voltageKnown for one	52 - 56 V	Unknown — not stated by the source
Power consumption (max)Differs	3.2 W	3 W
Power over Ethernet (PoE)	Yes	Yes
Output voltageKnown for one	Unknown — not stated by the source	56 V
Operational conditions2 differ
Operating temperature (T-T)	0 - 50 °C	0 - 50 °C
Storage temperature (T-T)Differs	-10 - 85 °C	-10 - 70 °C
Operating relative humidity (H-H)Differs	5 - 95%	5 - 90%
Weight & dimensions4 differ
WidthDiffers	69 mm	77 mm
DepthDiffers	94 mm	140 mm
HeightDiffers	25 mm	27 mm
WeightDiffers	193 g	239 g
Packaging contentidentical
ManualKnown for one	Yes	Unknown — not stated by the source
Quick start guideKnown for one	Unknown — not stated by the source	Yes
Packaging data4 differ
Package widthDiffers	138 mm	123 mm
Package depthDiffers	205 mm	169 mm
Package heightDiffers	72 mm	99 mm
Package weightDiffers	343 g	367 g
Certificatesidentical
Compliance certificates	RoHS	RoHS
Logistics dataidentical
Harmonized System (HS) code	85176990	85176990
Master (outer) case widthKnown for one	368 mm	Unknown — not stated by the source
Master (outer) case lengthKnown for one	578 mm	Unknown — not stated by the source
Master (outer) case heightKnown for one	300 mm	Unknown — not stated by the source
Products per master (outer) caseKnown for one	26 pc(s)	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
