Product comparison · 2 network cards

Shuttle PN15 network card WLAN 54 Mbit/s vs Shuttle Wireless LAN Module

12specifications compared
8differ
4identical
23known for one product only

Key differences

Compatible operating systems
- PN15 network card WLAN 54 Mbit/s:Windows 98SE/ME/2K/XP
- Wireless LAN Module:Windows 2000/XP/Vista, Linux
Width
- PN15 network card WLAN 54 Mbit/s:25 mm
- Wireless LAN Module:20 mm
Depth
- PN15 network card WLAN 54 Mbit/s:60 mm
- Wireless LAN Module:78 mm
Height
- PN15 network card WLAN 54 Mbit/s:4.3 mm
- Wireless LAN Module:4 mm
Weight
- PN15 network card WLAN 54 Mbit/s:7.5 g
- Wireless LAN Module:3 g
Compliance industry standards
- PN15 network card WLAN 54 Mbit/s:IEEE802.11g
- Wireless LAN Module:WiFi IEEE 802.11b/g
Dimensions (WxDxH)
- PN15 network card WLAN 54 Mbit/s:25 x 60 x 4.3 mm
- Wireless LAN Module:20 x 78 x 4 mm

Side by side

Differences highlightedShow differences only

Comparison of PN15, Wireless LAN Module
35 specifications	A Shuttle PN15 network card WLAN 54 Mbit/s Model PN15 View product	B Shuttle Wireless LAN Module View product
Ports & interfacesidentical
Connectivity technology	Wireless	Wireless
Host interface	USB	USB
InterfaceKnown for one	WLAN	Unknown — not stated by the source
Networkidentical
Maximum data transfer rate	54 Mbit/s	54 Mbit/s
Ethernet LANKnown for one	Unknown — not stated by the source	Yes
BandwidthKnown for one	Unknown — not stated by the source	2.400 GHz
Wi-FiKnown for one	Yes	Unknown — not stated by the source
WLAN data transfer rates supportedKnown for one	54 Mbit/s	Unknown — not stated by the source
Security algorithmsKnown for one	128-bit WEP, 64-bit WEP, WPA	Unknown — not stated by the source
Media access protocolKnown for one	CSMA/CA ACK	Unknown — not stated by the source
Maximum operating distanceKnown for one	100 m	Unknown — not stated by the source
Design1 differ
Internal	No	No
Antenna typeDiffers	2 GSC	External Antenna, designed for Shuttle XPC
ChipsetKnown for one	Unknown — not stated by the source	Realtek RTL8187, RF Chip: Realtek RTL8225
CertificationKnown for one	Unknown — not stated by the source	FCC, CE
Product colourKnown for one	Grey, White	Unknown — not stated by the source
System requirements1 differ
Compatible operating systemsDiffers	Windows 98SE/ME/2K/XP	Windows 2000/XP/Vista, Linux
Operational conditionsidentical
Operating temperature (T-T)Known for one	Unknown — not stated by the source	0 - 50 °C
Storage temperature (T-T)Known for one	Unknown — not stated by the source	-20 - 80 °C
Operating relative humidity (H-H)Known for one	0 - 95%	Unknown — not stated by the source
Weight & dimensions4 differ
WidthDiffers	25 mm	20 mm
DepthDiffers	60 mm	78 mm
HeightDiffers	4.3 mm	4 mm
WeightDiffers	7.5 g	3 g
Other features2 differ
Compliance industry standardsDiffers	IEEE802.11g	WiFi IEEE 802.11b/g
Dimensions (WxDxH)Differs	25 x 60 x 4.3 mm	20 x 78 x 4 mm
Supported data transfer ratesKnown for one	Unknown — not stated by the source	6, 9, 12, 18, 24, 36, 48, 54
Supported protocolsKnown for one	Unknown — not stated by the source	64/128 bit WEP / WPA / WPA2
Wireless connectionKnown for one	Unknown — not stated by the source	Yes
Outdoor rangeKnown for one	Unknown — not stated by the source	400 m
Indoor rangeKnown for one	Unknown — not stated by the source	100 m
I/O portsKnown for one	Unknown — not stated by the source	USB2.0 Interface, internal connector for Shuttle XPC
Power requirementsKnown for one	5V	Unknown — not stated by the source
Recommended operating temperature range (T-T)Known for one	0 - 65 °C	Unknown — not stated by the source
Poweridentical
Power consumptionKnown for one	22 mA	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
