Legrand Network interface Built-in + WiFi Dongle vs Legrand CS102 Internal Ethernet 1000 Mbit/s

Comparison of 311059, CS102

29 specifications	A Legrand Network interface Built-in + WiFi Dongle Model 311059 View product	B Legrand CS102 Internal Ethernet 1000 Mbit/s Model CS102 View product
Ports & interfacesidentical
Connectivity technology	Wired	Wired
Interface	Ethernet	Ethernet
Ethernet LAN (RJ-45) ports	2	2
USB ports quantity	2	2
Networkidentical
Maximum data transfer rate	1000 Mbit/s	1000 Mbit/s
Ethernet LAN	Yes	Yes
Ethernet interface type	Gigabit Ethernet	Gigabit Ethernet
Wake-on-LAN ready	Yes	Yes
Supported network protocols	IPv4, IPv6, DHCP, DNS, HTTP, HTTPS, SSH, NTP, SMTP, SNMP, MODBUS TCP, Wake on LAN, UPnP, RADIUS	IPv4, IPv6, DHCP, DNS, HTTP, HTTPS, SSH, NTP, SMTP, SNMP, MODBUS TCP, Wake on LAN, UPnP, RADIUS
Designidentical
Internal	Yes	Yes
Component for	Uninterruptible power supply (UPS)	Uninterruptible power supply (UPS)
Product colourKnown for one	—Unknown — not stated by the source	Grey
LED indicators	Error	Error
Poweridentical
Output voltage	5.5 - 40 V	5.5 - 40 V
Power consumption (typical)	3 W	3 W
System requirementsidentical
Windows operating systems supportedKnown for one	—Unknown — not stated by the source	Yes
Linux operating systems supportedKnown for one	—Unknown — not stated by the source	Yes
Operational conditions1 differ
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)Differs	-25 - 55 °C	0 - 60 °C
Operating relative humidity (H-H)	20 - 95%	20 - 95%
Weight & dimensionsidentical
Width	68 mm	68 mm
Depth	133 mm	133 mm
Height	43 mm	43 mm
Weight	69 g	69 g
Packaging contentidentical
Mounting brackets included	Yes	Yes
Quick installation guide	Yes	Yes
Other featuresidentical
Processor frequency	180 MHz	180 MHz
Processor architecture	ARM9	ARM9
Flash memory	8 MB	8 MB

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
