Product comparison · 2 network antennas

Lindy 52109 network antenna Omni-directional antenna RP-SMA 7 dBi vs Lindy 52111 network antenna Directional antenna RP-SMA 8 dBi

Key differences

Antenna gain level (max)
- 52109 network antenna Omni-directional antenna RP-SMA 7 dBi:7 dBi
- 52111 network antenna Directional antenna RP-SMA 8 dBi:8 dBi
Frequency band
- 52109 network antenna Omni-directional antenna RP-SMA 7 dBi:2.4 GHz
- 52111 network antenna Directional antenna RP-SMA 8 dBi:2.4 - 2.4835 GHz
Antenna type
- 52109 network antenna Omni-directional antenna RP-SMA 7 dBi:Omni-directional antenna
- 52111 network antenna Directional antenna RP-SMA 8 dBi:Directional antenna
Product colour
- 52109 network antenna Omni-directional antenna RP-SMA 7 dBi:Black
- 52111 network antenna Directional antenna RP-SMA 8 dBi:White

Differences highlightedShow differences only

Comparison of 52109, 52111
19 specifications	A Lindy 52109 network antenna Omni-directional antenna RP-SMA 7 dBi Model 52109 View product	B Lindy 52111 network antenna Directional antenna RP-SMA 8 dBi Model 52111 View product
Performance2 differ
Antenna gain level (max)Differs	7 dBi	8 dBi
Frequency bandDiffers	2.4 GHz	2.4 - 2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Impedance	50 Ω	50 Ω
Horizontal beam width (2.4 GHz)Known for one	360°	Unknown — not stated by the source
Vertical beam width (2.4 GHz)Known for one	40°	Unknown — not stated by the source
GainKnown for one	Unknown — not stated by the source	8 dBi
Features2 differ
Antenna typeDiffers	Omni-directional antenna	Directional antenna
Antenna connector type	RP-SMA	RP-SMA
Polarization	Vertical polarization	Vertical polarization
Voltage Standing Wave Ratio (VSWR)	2.0	2.0
Product colourDiffers	Black	White
Cable length	1 m	1 m
Operational conditionsidentical
Operating temperature (T-T)Known for one	-10 - 55 °C	Unknown — not stated by the source
Operating relative humidity (H-H)Known for one	5 - 95%	Unknown — not stated by the source
Weight & dimensionsidentical
WidthKnown for one	12 mm	Unknown — not stated by the source
DepthKnown for one	12 mm	Unknown — not stated by the source
HeightKnown for one	300 mm	Unknown — not stated by the source
Packaging contentidentical
Quantity per packKnown for one	Unknown — not stated by the source	1 pc(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
