Product comparison · 2 nas & storage servers

TERRA NASBOX 5-2002 G3 vs TERRA NASBOX 5-2012 G3 (12 TB)

90specifications compared
4differ
86identical
11known for one product only

Key differences

Total installed storage capacity
- NASBOX 5-2002 G3:2 TB
- TERRA NASBOX 5-2012 G3 (12 TB):12 TB
Storage drive capacity
- NASBOX 5-2002 G3:1 TB
- TERRA NASBOX 5-2012 G3 (12 TB):12 TB
Storage drive interface
- NASBOX 5-2002 G3:Serial ATA II
- TERRA NASBOX 5-2012 G3 (12 TB):Serial ATA
Weight
- NASBOX 5-2002 G3:9.3 kg
- TERRA NASBOX 5-2012 G3 (12 TB):9.9 kg

Side by side

Differences highlightedShow differences only

Comparison of NASBOX 5-2002 G3, TERRA NASBOX 5-2012 G3 (12 TB)
101 specifications	A TERRA NASBOX 5-2002 G3 View product	B TERRA TERRA NASBOX 5-2012 G3 (12 TB)View product
Storage3 differ
Storage drives installed	Yes	Yes
Total installed storage capacityDiffers	2 TB	12 TB
Number of storage drives installed	2	2
Number of storage drives supported	5	5
Installed storage drive type	HDD	HDD
Supported storage drive types	HDD	HDD
Storage drive capacityDiffers	1 TB	12 TB
Storage drive interfaceDiffers	Serial ATA II	Serial ATA
Storage drive size	3.5"	3.5"
HDD speed	5400 RPM	5400 RPM
Maximum supported storage capacity	30 TB	30 TB
RAID support	Yes	Yes
RAID levelsKnown for one	Unknown — not stated by the source	0, 1, 5, 6, 10, JBOD
Hot-swap drive bays	Yes	Yes
Supported file systemsKnown for one	Unknown — not stated by the source	NTFS, ext4
Processoridentical
Processor manufacturer	Intel	Intel
Processor family	Intel® Celeron®	Intel® Celeron®
Processor model	J1900	J1900
Processor frequency	2 GHz	2 GHz
Processor boost frequency	2.42 GHz	2.42 GHz
Processor cores	4	4
Processor threads	4	4
Processor cache	2 MB	2 MB
CPU configuration (max)	1	1
ECC supported by processor	No	No
PCI Express configurations	1x4	1x4
PCI Express slots version	2.0	2.0
Physical Address Extension (PAE)	36 bit	36 bit
Processor cache type	L2	L2
Processor code	SR1SC	SR1SC
Processor codename	Bay Trail	Bay Trail
Processor lithography	22 nm	22 nm
Processor operating modes	32-bit, 64-bit	32-bit, 64-bit
Processor package size	25 X 27 mm	25 X 27 mm
Processor series	Intel Celeron Processor J1000 series for Desktop	Intel Celeron Processor J1000 series for Desktop
Processor socket	BGA 1170	BGA 1170
Stepping	B3	B3
Thermal Design Power (TDP)	10 W	10 W
Tjunction	105 °C	105 °C
On-board graphics card model	Intel® HD Graphics	Intel® HD Graphics
Maximum internal memory supported by processor	8 GB	8 GB
Conflict-Free processor	Yes	Yes
Memoryidentical
Internal memory	4 GB	4 GB
Internal memory type	DDR3	DDR3
Networkidentical
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
DHCP clientKnown for one	Unknown — not stated by the source	Yes
iSCSI supportKnown for one	Unknown — not stated by the source	Yes
Ports & interfacesidentical
Ethernet LAN (RJ-45) ports	5	5
USB portKnown for one	Unknown — not stated by the source	Yes
USB 2.0 ports quantity	2	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3	3
HDMI ports quantity	1	1
Fiber ports quantityKnown for one	0	Unknown — not stated by the source
Graphicsidentical
On-board graphics card base frequency	688 MHz	688 MHz
On-board graphics card dynamic frequency (max)	854 MHz	854 MHz
Number of displays supported (on-board graphics)	2	2
Designidentical
Product colour	Black	Black
Performanceidentical
Type	NAS	NAS
Device classKnown for one	Unknown — not stated by the source	Small & Medium Business
Backup functionKnown for one	Unknown — not stated by the source	Yes
Backup featuresKnown for one	Unknown — not stated by the source	Cloud
Built-in FTP server	Yes	Yes
Built-in Samba serverKnown for one	Unknown — not stated by the source	Yes
Built-in UPnP AV media serverKnown for one	Unknown — not stated by the source	Yes
Network Time Protocol (NTP) client	Yes	Yes
Softwareidentical
Operating system installed	Linux	Linux
Operating system version	Fedora	Fedora
Poweridentical
Power consumption (typical)	200 W	200 W
AC input voltage	120-230 V	120-230 V
AC input frequency	50 - 60 Hz	50 - 60 Hz
Weight & dimensions1 differ
Width	190 mm	190 mm
Depth	230 mm	230 mm
Height	240 mm	240 mm
WeightDiffers	9.3 kg	9.9 kg
Processor special featuresidentical
Embedded options available	Yes	Yes
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Graphics & IMC lithography	22 nm	22 nm
Intel 64	Yes	Yes
Intel FDI Technology	No	No
Intel Identity Protection Technology version	0.00	0.00
Intel Rapid Storage Technology	No	No
Intel Small Business Advantage (SBA) version	0.00	0.00
Intel Stable Image Platform Program (SIPP)	No	No
Intel Stable Image Platform Program (SIPP) version	0.00	0.00
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No	No
Intel® AES New Instructions (Intel® AES-NI)	No	No
Intel® Anti-Theft Technology (Intel® AT)	No	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No	No
Intel® Identity Protection Technology (Intel® IPT)	No	No
Intel® InTru™ 3D Technology	No	No
Intel® Insider™	No	No
Intel® Quick Sync Video Technology	Yes	Yes
Intel® Turbo Boost Technology	No	No
Intel® Wireless Display (Intel® WiDi)	No	No
Maximum number of PCI Express lanes	4	4
Memory channels supported by processor	Dual	Dual
Memory types supported by processor	DDR3L-SDRAM	DDR3L-SDRAM
Other featuresidentical
Processor ARK ID	78867	78867

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
