Product comparison · 2 monitors crt

Philips 105E 15" FST .28 120Hz MPR2 OSD vs Philips 107E56/00 monitor CRT

8specifications compared
7differ
1identical
13known for one product only

Key differences

Display diagonal
- 105E 15" FST .28 120Hz MPR2 OSD:38.1 cm (15")
- 107E56/00 monitor CRT:43.2 cm (17")
Viewable size diagonal
- 105E 15" FST .28 120Hz MPR2 OSD:35.5 cm
- 107E56/00 monitor CRT:23 cm
Vertical scan range
- 105E 15" FST .28 120Hz MPR2 OSD:50 - 120 Hz
- 107E56/00 monitor CRT:50 - 160 Hz
Horizontal scan range
- 105E 15" FST .28 120Hz MPR2 OSD:30 - 54 kHz
- 107E56/00 monitor CRT:30 - 70 kHz
Dimensions (WxDxH)
- 105E 15" FST .28 120Hz MPR2 OSD:358 x 379 x 380 mm
- 107E56/00 monitor CRT:419 x 383 x 397 mm
Weight
- 105E 15" FST .28 120Hz MPR2 OSD:11.7 kg
- 107E56/00 monitor CRT:14 kg

Side by side

Differences highlightedShow differences only

Comparison of 105E 15" FST .28 120Hz MPR2 OSD, 107E56/00
21 specifications	A Philips 105E 15" FST .28 120Hz MPR2 OSD View product	B Philips 107E56/00 monitor CRT Model 107E56/00 View product
Display5 differ
Display diagonalDiffers	38.1 cm (15")	43.2 cm (17")
TypeDiffers	Display / CRT Conventional	CRT . Shadow mask, flat square, high contrast
Display resolution	1024 x 768 pixels	1024 x 768 pixels
Viewable size, verticalKnown for one	Unknown — not stated by the source	41 cm
Viewable size, horizontalKnown for one	Unknown — not stated by the source	30.6 cm
Viewable size diagonalDiffers	35.5 cm	23 cm
Vertical scan rangeDiffers	50 - 120 Hz	50 - 160 Hz
Horizontal scan rangeDiffers	30 - 54 kHz	30 - 70 kHz
DisplayKnown for one	Shadow mask, FST, AGASC, Light Transmission 57%	Unknown — not stated by the source
Featuresidentical
Display tilt and swivel rangeKnown for one	Unknown — not stated by the source	90
Audio systemKnown for one	No	Unknown — not stated by the source
Plug and PlayKnown for one	Yes	Unknown — not stated by the source
CertificationKnown for one	MPR-II Low Emission, TüV GS, TüV-Ergonomie, TüV 9241-3, FCC-B, UL, CSA, DHHS, SEMKO, Poland-B sign, C-Tick, VCC-1, CE, BCIQ, PSB	Unknown — not stated by the source
Poweridentical
Monitor maximum power consumptionKnown for one	Unknown — not stated by the source	75 W
Operational conditionsidentical
Operating relative humidity (H-H)Known for one	Unknown — not stated by the source	5 - 95%
Operating temperature (T-T)Known for one	Unknown — not stated by the source	0 - 40 °C
Weight & dimensions2 differ
Dimensions (WxDxH)Differs	358 x 379 x 380 mm	419 x 383 x 397 mm
WeightDiffers	11.7 kg	14 kg
Technical detailsidentical
Monitor max. video input bandwidthKnown for one	Unknown — not stated by the source	108 MHz
Ports & interfacesidentical
I/O portsKnown for one	15-pin D-Shell	Unknown — not stated by the source
Management featuresidentical
User controlsKnown for one	Increase, Decrease, H-shift, H-size, V-shift, V-size, Shift to second level, Trapezoid, Pincushion, Recall, Power on/off, Contrast, Brightness	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
