Product comparison · 2 monitors crt

EIZO 19IN 25MM 1280X1024 160HZ vs EIZO T966 21IN FD-TRINITRON

11specifications compared
9differ
2identical
15known for one product only

Key differences

Display diagonal
- 19IN 25MM 1280X1024 160HZ:48.3 cm (19")
- T966 21IN FD-TRINITRON:53.3 cm (21")
Display resolution
- 19IN 25MM 1280X1024 160HZ:1920 x 1440 pixels
- T966 21IN FD-TRINITRON:2048 x 1536 pixels
Viewable size diagonal
- 19IN 25MM 1280X1024 160HZ:45.2 cm
- T966 21IN FD-TRINITRON:49.8 cm
Vertical scan range
- 19IN 25MM 1280X1024 160HZ:50 - 160 Hz
- T966 21IN FD-TRINITRON:160
Horizontal scan range
- 19IN 25MM 1280X1024 160HZ:30 - 115 kHz
- T966 21IN FD-TRINITRON:130
Weight
- 19IN 25MM 1280X1024 160HZ:26.7 kg
- T966 21IN FD-TRINITRON:36 g
Monitor max. video input bandwidth
- 19IN 25MM 1280X1024 160HZ:280 MHz
- T966 21IN FD-TRINITRON:340 MHz

Side by side

Differences highlightedShow differences only

Comparison of 19IN 25MM 1280X1024 160HZ, T966 21IN FD-TRINITRON
26 specifications	A EIZO 19IN 25MM 1280X1024 160HZ View product	B EIZO T966 21IN FD-TRINITRON View product
Display6 differ
Display diagonalDiffers	48.3 cm (19")	53.3 cm (21")
TypeDiffers	Display / CRT conventional - desktop	90° deflection Tension Mask, Super ErgoCoat
Display resolutionDiffers	1920 x 1440 pixels	2048 x 1536 pixels
Viewable size diagonalDiffers	45.2 cm	49.8 cm
Vertical scan rangeDiffers	50 - 160 Hz	160
Horizontal scan rangeDiffers	30 - 115 kHz	130
Maximum resolutionKnown for one	Unknown — not stated by the source	2048 x 1536 pixels
Pixel pitchKnown for one	Unknown — not stated by the source	0.24
Recommended resolutionKnown for one	Unknown — not stated by the source	1600 dots × 1200 lines @ 104 Hz1
Viewable size, verticalKnown for one	27.1 cm	Unknown — not stated by the source
Viewable size, horizontalKnown for one	36.2 cm	Unknown — not stated by the source
DisplayKnown for one	Flat-faced aperture grill CRT	Unknown — not stated by the source
Surface treatmentKnown for one	Super ErgoCoat	Unknown — not stated by the source
Features1 differ
Audio system	No	No
CertificationDiffers	TCO99, TUV ECO Circle 2000, TUV/GS, c-Tick, CE, CB, UL 1950, CSA C22.2 No.950, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA ENERGY STAR Program, Energy 2000	TCO'992, TÜV ECO Circle 2001, TÜV/GS, c-Tick, CE, CB, UL 1950, CSA C22.2 No.950, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA ENERGY STAR Program, DHHS (DNHW), German X-Ray Law
Plug and PlayKnown for one	Yes	Unknown — not stated by the source
Poweridentical
Power managementKnown for one	Unknown — not stated by the source	VESA DPMS
Power sourceKnown for one	Unknown — not stated by the source	AC 100 - 120V / 200 - 240V, 50 - 60 Hz
Monitor maximum power consumptionKnown for one	Unknown — not stated by the source	160 W
Management featuresidentical
User controls	ScreenManager, ScreenManager Pro for USB, One Touch Auto Adjustment Function (Auto-Sizing)	ScreenManager, ScreenManager Pro for USB, One Touch Auto Adjustment Function (Auto-Sizing)
Weight & dimensions1 differ
DepthKnown for one	Unknown — not stated by the source	520 mm
WeightDiffers	26.7 kg	36 g
WidthKnown for one	Unknown — not stated by the source	494 mm
Dimensions (WxDxH)Known for one	452 x 478 x 455 mm	Unknown — not stated by the source
Technical details1 differ
Monitor max. video input bandwidthDiffers	280 MHz	340 MHz
Ports & interfacesidentical
I/O portsKnown for one	D-Sub 15-pin, 5 x BNC (switchable), USB 1.1: 1 x upstream, 4x downstream ports	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
