Product comparison · 2 computer cooling systems

CoolBox Plannar 120 vs CoolBox VENCOOAU120 Computer case Fan

17specifications compared
8differ
9identical
12known for one product only

Key differences

Suitable location
- Plannar 120:Processor
- VENCOOAU120 Computer case Fan:Computer case
Type
- Plannar 120:Cooler
- VENCOOAU120 Computer case Fan:Fan
Rotational speed (max)
- Plannar 120:1600 RPM
- VENCOOAU120 Computer case Fan:1500 RPM
Maximum airflow
- Plannar 120:56 cfm
- VENCOOAU120 Computer case Fan:53.4 cfm
Maximum air pressure
- Plannar 120:1.7 mmH2O
- VENCOOAU120 Computer case Fan:1.81 mmH2O
Depth
- Plannar 120:120 mm
- VENCOOAU120 Computer case Fan:25 mm
Height
- Plannar 120:63 mm
- VENCOOAU120 Computer case Fan:120 mm

Side by side

Differences highlightedShow differences only

Comparison of Plannar 120, VENCOOAU120
29 specifications	A CoolBox Plannar 120 View product	B CoolBox VENCOOAU120 Computer case Fan Model VENCOOAU120 View product
Performance6 differ
Suitable locationDiffers	Processor	Computer case
TypeDiffers	Cooler	Fan
Fan diameter	12 cm	12 cm
Supported processor socketsDiffers	Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket FM1, Socket FM2, Socket FM2+, LGA 1151 (Socket H4)	Not supported
Rotational speed (min)Known for one	800 RPM	Unknown — not stated by the source
Rotational speed (max)Differs	1600 RPM	1500 RPM
Noise level (low speed)Known for one	16 dB	Unknown — not stated by the source
Noise level (high speed)Known for one	20.2 dB	Unknown — not stated by the source
Maximum airflowDiffers	56 cfm	53.4 cfm
Maximum air pressureDiffers	1.7 mmH2O	1.81 mmH2O
Mean time between failures (MTBF)	30000 h	30000 h
Compatible processor seriesKnown for one	Unknown — not stated by the source	Not supported
Designidentical
Product colour	Black	Black
MaterialKnown for one	Aluminium	Unknown — not stated by the source
Number of fans	1 fan(s)	1 fan(s)
Fan connector	4-pin	4-pin
Poweridentical
Power consumption (typical)	1.8 W	1.8 W
Voltage	12 V	12 V
Rated currentKnown for one	0.15 A	Unknown — not stated by the source
Thermal Design Power (TDP)Known for one	100 W	Unknown — not stated by the source
Weight & dimensions2 differ
Width	120 mm	120 mm
DepthDiffers	120 mm	25 mm
HeightDiffers	63 mm	120 mm
WeightKnown for one	250 g	Unknown — not stated by the source
Fan dimensions (W x D x H)Known for one	120 x 120 x 25 mm	Unknown — not stated by the source
Fan thicknessKnown for one	2.5 cm	Unknown — not stated by the source
Technical detailsidentical
Bearing technology	Hydraulic	Hydraulic
Compliance certificatesKnown for one	Unknown — not stated by the source	RoHS
Other featuresidentical
Connector(s)Known for one	Unknown — not stated by the source	Molex

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
