Product comparison · 2 all-in-one pcs/workstations

Nilox NX24AIOI38100WE Intel® Core™ i3 i3-8100 vs Nilox W10PRO Intel® Core™ i3 i3-8100

101specifications compared
13differ
88identical
21known for one product only

Key differences

Display diagonal
- NX24AIOI38100WE Intel® Core™ i3 i3-8100:61 cm (24")
- W10PRO Intel® Core™ i3 i3-8100:60.5 cm (23.8")
Display resolution
- NX24AIOI38100WE Intel® Core™ i3 i3-8100:1080 x 1920 pixels
- W10PRO Intel® Core™ i3 i3-8100:1920 x 1080 pixels
Touchscreen
- NX24AIOI38100WE Intel® Core™ i3 i3-8100:Yes
- W10PRO Intel® Core™ i3 i3-8100:No
Internal memory
- NX24AIOI38100WE Intel® Core™ i3 i3-8100:4 GB
- W10PRO Intel® Core™ i3 i3-8100:8 GB
Memory clock speed
- NX24AIOI38100WE Intel® Core™ i3 i3-8100:2133 MHz
- W10PRO Intel® Core™ i3 i3-8100:2400 MHz
Number of SSDs installed
- NX24AIOI38100WE Intel® Core™ i3 i3-8100:2
- W10PRO Intel® Core™ i3 i3-8100:1
VGA (D-Sub) ports quantity
- NX24AIOI38100WE Intel® Core™ i3 i3-8100:0
- W10PRO Intel® Core™ i3 i3-8100:1
Product colour
- NX24AIOI38100WE Intel® Core™ i3 i3-8100:Black
- W10PRO Intel® Core™ i3 i3-8100:White

Side by side

Differences highlightedShow differences only

Comparison of NX24AIOI38100WE, W10PRO
122 specifications	A Nilox NX24AIOI38100WE Intel® Core™ i3 i3-8100 Model NX24AIOI38100WE View product	B Nilox W10PRO Intel® Core™ i3 i3-8100 Model W10PRO View product
Display3 differ
Display diagonalDiffers	61 cm (24")	60.5 cm (23.8")
Display resolutionDiffers	1080 x 1920 pixels	1920 x 1080 pixels
TouchscreenDiffers	Yes	No
HD typeKnown for one	HD	Unknown — not stated by the source
Native aspect ratio	16:9	16:9
Display brightness	300 cd/m²	300 cd/m²
Processoridentical
Processor manufacturer	Intel	Intel
Processor family	Intel® Core™ i3	Intel® Core™ i3
Processor generation	8th gen Intel® Core™ i3	8th gen Intel® Core™ i3
Processor model	i3-8100	i3-8100
Processor cores	4	4
Processor threads	4	4
Processor frequency	3.6 GHz	3.6 GHz
Processor cache	6 MB	6 MB
Processor cache type	Smart Cache	Smart Cache
Processor socket	LGA 1151 (Socket H4)	LGA 1151 (Socket H4)
System bus rate	8 GT/s	8 GT/s
Thermal Design Power (TDP)	65 W	65 W
Bus type	DMI3	DMI3
Maximum number of PCI Express lanes	16	16
PCI Express configurations	1x16, 1x8+2x4, 2x8	1x16, 1x8+2x4, 2x8
PCI Express slots version	3.0	3.0
Processor codename	Coffee Lake	Coffee Lake
Processor lithography	14 nm	14 nm
Processor operating modes	64-bit	64-bit
Tjunction	100 °C	100 °C
Conflict-Free processor	Yes	Yes
Maximum internal memory supported by processor	64 GB	64 GB
Memory types supported by processor	DDR4-SDRAM	DDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz	2400 MHz
Memory bandwidth supported by processor (max)	37.5 GB/s	37.5 GB/s
Memory2 differ
Internal memoryDiffers	4 GB	8 GB
Internal memory type	DDR4-SDRAM	DDR4-SDRAM
Maximum internal memory	32 GB	32 GB
Memory slotsKnown for one	2	Unknown — not stated by the source
Memory slots type	SO-DIMM	SO-DIMM
Memory clock speedDiffers	2133 MHz	2400 MHz
Storage1 differ
Total storage capacity	240 GB	240 GB
Storage media	SSD	SSD
Number of SSDs installedDiffers	2	1
SSD capacity	240 GB	240 GB
SSD interface	SATA III	SATA III
Total SSDs capacityKnown for one	Unknown — not stated by the source	240 GB
Optical drive typeKnown for one	Unknown — not stated by the source	No
Card reader integratedKnown for one	Unknown — not stated by the source	Yes
Graphicsidentical
Discrete graphics cardKnown for one	No	Unknown — not stated by the source
On-board graphics card	Yes	Yes
On-board graphics card familyKnown for one	Intel® HD Graphics	Unknown — not stated by the source
On-board graphics card model	Intel® UHD Graphics 630	Intel® UHD Graphics 630
Maximum on-board graphics card memory	64 GB	64 GB
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	350 MHz	350 MHz
On-board graphics card dynamic frequency (max)	1100 MHz	1100 MHz
On-board graphics card DirectX version	12.0	12.0
On-board graphics card ID	0x3E91	0x3E91
On-board graphics card OpenGL version	4.5	4.5
Number of execution units	23	23
On-board GPU manufacturerKnown for one	Unknown — not stated by the source	Intel
Cameraidentical
Built-in camera	Yes	Yes
Total megapixelsKnown for one	2 MP	Unknown — not stated by the source
Networkidentical
Wi-Fi	Yes	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)	Wi-Fi 5 (802.11ac)
Wi-Fi standards	Wi-Fi 5 (802.11ac)	Wi-Fi 5 (802.11ac)
Ethernet LANKnown for one	Yes	Unknown — not stated by the source
Ethernet LAN data ratesKnown for one	10,100,1000 Mbit/s	Unknown — not stated by the source
Bluetooth	Yes	Yes
Ports & interfaces1 differ
Thunderbolt ports quantityKnown for one	0	Unknown — not stated by the source
HDMI ports quantity	1	1
VGA (D-Sub) ports quantityDiffers	0	1
DisplayPorts quantityKnown for one	0	Unknown — not stated by the source
Mini DisplayPorts quantityKnown for one	0	Unknown — not stated by the source
USB 2.0 ports quantityKnown for one	Unknown — not stated by the source	4
Design1 differ
Product colourDiffers	Black	White
Panel mounting interfaceKnown for one	100 x 100 mm	Unknown — not stated by the source
VESA mountingKnown for one	Yes	Unknown — not stated by the source
Performanceidentical
Product type	All-in-One PC	All-in-One PC
Software1 differ
Operating system installedDiffers	Windows 10	Windows 10 Pro
Operating system architecture	64-bit	64-bit
Processor special featuresidentical
CPU configuration (max)	1	1
Embedded options available	Yes	Yes
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	Yes	Yes
Intel Enhanced Halt State	Yes	Yes
Intel Identity Protection Technology version	1.00	1.00
Intel Secure Key Technology version	1.00	1.00
Intel Software Guard Extensions (Intel SGX)	Yes	Yes
Intel Stable Image Platform Program (SIPP)	No	No
Intel Stable Image Platform Program (SIPP) version	0.00	0.00
Intel TSX-NI	No	No
Intel TSX-NI version	0.00	0.00
Intel Trusted Execution Technology	No	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No	No
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Intel® InTru™ 3D Technology	Yes	Yes
Intel® OS Guard	Yes	Yes
Intel® Quick Sync Video Technology	Yes	Yes
Intel® Secure Key	Yes	Yes
Intel® Turbo Boost Technology	No	No
Processor ARK ID	126688	126688
Processor package size	37.5 x 37.5 mm	37.5 x 37.5 mm
Scalability	1S	1S
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specification	PCG 2015C	PCG 2015C
Poweridentical
AC adapter power	90 W	90 W
Weight & dimensions4 differ
Width (with stand)Differs	530 mm	540 mm
Depth (with stand)Differs	150 mm	143 mm
Height (with stand)Differs	400 mm	410 mm
Weight (with stand)Differs	6 kg	4 kg
Packaging contentidentical
Mouse includedKnown for one	No	Unknown — not stated by the source
Keyboard includedKnown for one	No	Unknown — not stated by the source
Audioidentical
Built-in speaker(s)Known for one	Unknown — not stated by the source	Yes
Other featuresidentical
Power supplyKnown for one	Unknown — not stated by the source	90 W

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
