KAC-9105D car audio amplifier D
Model KAC-9105D
24 specifications
- ConnectivityWired
- Weight3.3 kg
- ColourBlack
- Amplifier classD
- Line inputs (RCA)1
- Maximum current57 A
Overview
- Connectivity
- Wired
- Weight
- 3.3 kg
- Colour
- Black
- Amplifier class
- D
- Line inputs (RCA)
- 1
- Maximum current
- 57 A
- Brand
- Kenwood
- Category
- Car Audio Amplifier
- Model
- KAC-9105D
- Part number
- KAC-9105D
- Also known as
- Kenwood KAC-9105D car audio amplifier D
Specifications
24 specifications in 6 groups
Performance
| Specification | Value |
|---|---|
| Amplifier class | D |
| Peak power per channel | 1800 W |
| Low pass filter | Yes |
| Input impedance | 10000 Ω |
| RMS power output per channel (1 Ohm) | 900 W |
| Total Harmonic Distortion (THD) | 1% |
| RMS power output per channel (4 Ohm) | 500 W |
| Input sensitivity | 5 mV |
| Bass boost | 0 - 18 dB |
| Frequency range | 5 - 200 Hz |
| LED indicators | Yes |
| Phase shift | 0 - 180° |
| Signal-to-Noise Ratio (SNR) | 100 dB |
Ports & interfaces
| Specification | Value |
|---|---|
| Line inputs (RCA) | 1 |
| Line outputs (RCA) | 1 |
Features
| Specification | Value |
|---|---|
| Product colour | Black |
Technical details
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Bass adjustment | Yes |
| Cooling type | Active |
Power
| Specification | Value |
|---|---|
| Maximum current | 57 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 350 mm |
| Depth | 238 mm |
| Height | 59 mm |
| Weight | 3.3 kg |
