R7 RF-S18-150mm F3.5-6.3 IS STM

Model R7 RF-S18-150mm F3.5-6.3 IS STMPart no. 5137C009EAN 013803340631

130 specifications Checked today

Display7.49 cm (2.95")
Resolution1024 x 768 pixels
Weight530 g
ColourBlack
Camera typeMILC Body
Focus adjustmentAuto/Manual

See all specifications

Overview

Display: 7.49 cm (2.95")
Resolution: 1024 x 768 pixels
Weight: 530 g
Colour: Black
Camera type: MILC Body
Focus adjustment: Auto/Manual

Brand: Canon
Category: Camera
Model: R7 RF-S18-150mm F3.5-6.3 IS STM
Part number: 5137C009
EAN / UPC: 013803340631
Also known as: Canon EOS R7 RF-S18-150mm F3.5-6.3 IS STM Lens Kit

Specifications

130 specifications in 19 groups

Picture quality

Specification	Value
Camera type	MILC Body
Megapixel (approx.)	32.5 MP
Sensor type	CMOS
Maximum image resolution	6960 x 4640 pixels
Still image resolution(s)	RAW/ C-RAW: 3:2 ratio 6960x4640 JPEG/ HEIF: 3:2 ratio (L) 6960x4640, (M) 4800x3200, (S1) 3472x2320, (S2) 2400x1600 4:3 ratio (L) 6160x4640, (M) 4256x3200, (S1) 3072x2320, (S2) 2112x1600 16:9 ratio (L) 6960x3904, (M) 4800x2688, (S1) 3472x1952, (S2) 2400x1344 1:1 ratio (L) 4640x4640, (M) 3200x3200, (S
Image stabilizer	Yes
Supported aspect ratios	3:2
Total megapixels	34.4 MP
Image formats supported	C-RAW, HEIF, JPEG, Raw

Focusing

Specification	Value
Focus adjustment	Auto/Manual
Focusing system	Dual Pixel CMOS AF II
Auto focusing (AF) modes	AI Focus, Single Auto Focus
Auto Focus (AF) object detection	Animal, Bird, Eye, Face, People, Vehicle
Face tracking	Yes
Auto Focus (AF) area (auto selection) (horizonlal/vertical)	100/100%
Auto Focus (AF) area (manual selection) (horizonlal/vertical)	90/100%
Auto Focus (AF) number of areas (auto selection)	651
Auto Focus (AF) points manual selection	AF point expansion 4 points, Flexible zone AF 1-3
Auto Focus (AF) points selection	Auto, Manual

Exposure

Specification	Value
ISO sensitivity (min)	100
ISO sensitivity (max)	51200
Light exposure modes	Auto, Manual
Light exposure correction	± 3EV (1/3EV step)
Light metering	Centre-weighted, Partial, Spot
Auto Exposure (AE) lock	Yes
Auto Exposure (AE) locking (manual)	AE lock button (P, Av, Fv, Tv, M modes)
Anti-flicker shooting	Yes
Exposure bracketing (AEB)	± 3EV (1/2EV; 1/3EV stop)
Flicker detection frequency	100 - 120 Hz

Shutter

Specification	Value
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Camera shutter type	Electronic
Camera shutter speed (bulb electronic)	30-1/16000 s
Camera shutter speed (mechanical)	30-1/8000 s
Shutter release type	Electromagnetic

Flash

Specification	Value
Flash modes	Second curtain synchro
Brand specific flash systems	E-TTL II (Canon)
Flash exposure bracketing	Yes
Flash exposure compensation	Yes
Flash exposure correction	±3EV (1/2; 1/3 EV step)
Flash exposure lock	Yes
Flash sync-speed	1/250 s

Video

Specification	Value
Video recording	Yes
Maximum video resolution	3840 x 2160 pixels
HD type	4K Ultra HD
Video resolutions	1920 x 1080,3840 x 2160 pixels
Motion JPEG frame rate	30 fps
Resolution at capture speed	1920x1080@25fps, 1920x1080@29.97fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@23.98fps, 3840x2160@25fps, 3840x2160@29.97fps, 3840x2160@60fps
Video recording ISO sensitivity (auto)	100-12800, H: 25600
Video recording ISO sensitivity (manual)	100-12800, H: 16000-25600

Audio

Specification	Value
Built-in microphone	Yes
Built-in speaker(s)	Yes
Voice recording	Yes

Memory

Specification	Value
Compatible memory cards	SD, SDHC, SDXC
Memory slots	2

Display

Specification	Value
Display	TFT
Touchscreen	No
Display diagonal	7.49 cm (2.95")
Display diagonal (metric)	7.5 cm
Display resolution	1024 x 768 pixels
Display resolution	1620000 dot
Display backlight	Yes
Viewing angle, horizontal	170°
Viewing angle, vertical	170°

Viewfinder

Specification	Value
Viewfinder type	Electronic
Depth of field preview	Yes
Magnification	1.15x
Viewfinder frame rate (power saving mode)	59.94 fps
Viewfinder frame rate (smooth mode)	119.98 fps
Viewfinder information	AF method, AF operation, AF point information, Anti-flicker shooting, Aperture, Aspect ratio, Auto Lighting Optimizer, Battery level, Bluetooth function, Digital Lens Optimizer, Drive mode, Electronic level, Exposure compensation, Exposure level indicator, Exposure simulation, FE lock, FEB, Flash of
Viewfinder technology	OLED
Viewfinder resolution (approx.)	2360000 pixels

Ports & interfaces

Specification	Value
PictBridge	Yes
USB version	3.2 Gen 2 (3.1 Gen 2)
HDMI	Yes
HDMI connector type	Micro
Headphone outputs	1
Microphone in	Yes
Headphone connectivity	3.5 mm

Network

Specification	Value
Bluetooth	Yes
Bluetooth version	4.2
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Near Field Communication (NFC)	No

Camera

Specification	Value
White balance	Auto
White balance compensation (Blue/Amber)	±9
White balance compensation (Magenta/Green)	±9
Custom white balance	Yes
Number of custom white balance settings	5
Scene modes	Auto, Landscape, Monochrome, Portrait, Standard, User defined
Shooting modes	Auto, Manual
Photo effects	Black&White, Neutral
Self-timer delay	2,10 s
Camera playback	Movie, Single image
Multi burst mode	Yes
Diopter adjustment (D-D)	-4 - 2
Dioptre correction	Yes
Colour space supported	RGB
High Dynamic Range (HDR) supported	Yes
Histogram options	Brightness, RGB
Languages support	Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Hindi, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Swedish, Thai, Turkish, Ukrainian, Vietnamese
Multi-shot	Yes
Multiple exposure	Yes
Playback zoom (min)	1.5x
Playback zoom number of steps	15
RAW image processing	Yes
Tripod mounting supported	Yes
Mac operating systems supported	Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 12.0 Monterey
Windows operating systems supported	Windows 10, Windows 11, Windows 8.1

Design

Specification	Value
Product colour	Black
Dustproof	Yes
Waterproof	Yes

Battery

Specification	Value
Battery technology	Lithium-Ion (Li-Ion)
Battery type	LP-E6NH
Number of batteries supported	1
Battery level indicator	Yes
Battery level indicator number of levels	6

Power

Specification	Value
USB Type-C charging port	Yes
USB Type-C required charging power (max)	7.5 W
USB Type-C required charging power (min)	7.5 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85%

Weight & dimensions

Specification	Value
Width	132 mm
Depth	91.7 mm
Height	90.4 mm
Weight	530 g
Weight (including battery)	612 g

Packaging content

Specification	Value
AC adapter included	Yes
Batteries included	Yes
Quick start guide	Yes
