EAP100-BRIDGE KIT
Model EAP100-BRIDGE KITEAN 840460601559
31 specifications
- Speed300 Mbit/s
- TypeNetwork bridge
- ColourWhite
- Antenna designInternal
- Wi-FiYes
- Ethernet LAN (RJ-45) ports3
Overview
- Speed
- 300 Mbit/s
- Type
- Network bridge
- Colour
- White
- Antenna design
- Internal
- Wi-Fi
- Yes
- Ethernet LAN (RJ-45) ports
- 3
- Brand
- TP-Link
- Category
- Bridges & Repeaters
- Model
- EAP100-BRIDGE KIT
- Part number
- EAP100-BRIDGE KIT
- EAN / UPC
- 840460601559, 1210002603768
- Also known as
- TP-Link Omada EAP100-BRIDGE KIT bridge/repeater Network bridge 300 Mbit/s White
Specifications
31 specifications in 13 groups
Data transmission
| Specification | Value |
|---|---|
| Maximum data transfer rate | 300 Mbit/s |
| Maximum transfer distance | 500 m |
Antenna
| Specification | Value |
|---|---|
| Antenna design | Internal |
| Antenna type | 2x2 |
| Antenna gain level (max) | 8 dBi |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Fast Ethernet |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 3 |
Security
| Specification | Value |
|---|---|
| MAC address filtering | Yes |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
Features
| Specification | Value |
|---|---|
| Product type | Network bridge |
| Mounting type | Wall/Pole |
| Product colour | White |
| International Protection (IP) code | IP65 |
| Reset button | Yes |
Power
| Specification | Value |
|---|---|
| DC input voltage | 12 V |
| Power consumption (max) | 4.8 W |
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -40 - 158 °F |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 79 mm |
| Depth | 60 mm |
| Height | 224 mm |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 2 pc(s) |
