FRITZ!Repeater 1200 AX
Model FRITZ!Repeater 1200 AXPart no. 20002973EAN 4023125029738
25 specifications
- Speed2400 Mbit/s
- TypeNetwork repeater
- Weight160 g
- ColourWhite
- Antenna designInternal
- Wi-FiYes
Overview
- Speed
- 2400 Mbit/s
- Type
- Network repeater
- Weight
- 160 g
- Colour
- White
- Antenna design
- Internal
- Wi-Fi
- Yes
- Brand
- FRITZ!
- Category
- Bridges & Repeaters
- Model
- FRITZ!Repeater 1200 AX
- Part numbers
- 20002973, 20002974
- EAN / UPC
- 4023125029738, 4023125029745
- Also known as
- Repeater 1200 AX Edition International
Specifications
25 specifications in 11 groups
Data transmission
| Specification | Value |
|---|---|
| Maximum data transfer rate | 2400 Mbit/s |
| Supported data transfer rates | 600 Mbit/s, 2400 Mbit/s |
Antenna
| Specification | Value |
|---|---|
| Antenna design | Internal |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 2400 Mbit/s |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA, WPA2, WPA3, WPS |
Features
| Specification | Value |
|---|---|
| Product type | Network repeater |
| Product colour | White |
Power
| Specification | Value |
|---|---|
| AC input voltage | 230 V |
| AC input frequency | 50 Hz |
| Power consumption (typical) | 4 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80 mm |
| Depth | 80 mm |
| Height | 37 mm |
| Weight | 160 g |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
| Quantity per pack | 1 pc(s) |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
