3000 AX
Model 3000 AXPart no. 20002988EAN 4023125029882
28 specifications
- Speed2400 Mbit/s
- TypeNetwork repeater
- ColourWhite
- Antenna designInternal
- Wi-FiYes
- Ethernet LAN (RJ-45) ports2
Overview
- Speed
- 2400 Mbit/s
- Type
- Network repeater
- Colour
- White
- Antenna design
- Internal
- Wi-Fi
- Yes
- Ethernet LAN (RJ-45) ports
- 2
- Brand
- FRITZ!
- Category
- Bridges & Repeaters
- Model
- 3000 AX
- Part number
- 20002988
- EAN / UPC
- 4023125029882
- Also known as
- Repeater 3000 AX Network repeater 2400 Mbit/s White
Specifications
28 specifications in 12 groups
Data transmission
| Specification | Value |
|---|---|
| Maximum data transfer rate | 2400 Mbit/s |
Antenna
| Specification | Value |
|---|---|
| Antenna design | Internal |
Wireless LAN features
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 4200 Mbit/s |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA, WPA2, WPS |
Features
| Specification | Value |
|---|---|
| Product type | Network repeater |
| Product colour | White |
| LED indicators | Activity |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| AC input voltage | 230 V |
| AC input frequency | 50 Hz |
| Power consumption (typical) | 11 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 90 mm |
| Depth | 145 mm |
| Height | 190 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | DC, LAN (RJ-45) |
| Quick installation guide | Yes |
Other features
| Specification | Value |
|---|---|
| Warranty period | 5 year(s) |
Packaging data
| Specification | Value |
|---|---|
| Package depth | 244 mm |
| Package height | 98 mm |
| Package weight | 760 g |
| Package width | 179 mm |
