MSI 24 6NC-023RU
MSI

24 6NC-023RU

Model 24 6NC-023RUPart no. 9S6-AE9311-023

146 specifications
  • Display59.9 cm (23.6")
  • Resolution1920 x 1080 pixels
  • ProcessorIntel® Core™ i3
  • Memory8 GB
  • Storage1 TB
  • GraphicsNVIDIA® GeForce® 930MX
See all specifications

Overview

Display
59.9 cm (23.6")
Resolution
1920 x 1080 pixels
Processor
Intel® Core™ i3
Memory
8 GB
Storage
1 TB
Graphics
NVIDIA® GeForce® 930MX
Brand
MSI
Model
24 6NC-023RU
Part number
9S6-AE9311-023
Also known as
MSI Pro 24 6NC-023RU Intel® Core™ i3 i3-6100 59.9 cm (23.6") 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 1 TB HDD NVIDIA® GeForce® 930MX Windows 10 Home Bl

Specifications

146 specifications in 17 groups

Display

Display diagonal59.9 cm (23.6")
Display resolution1920 x 1080 pixels
TouchscreenNo
HD typeFull HD
LED backlightYes
Native aspect ratio16:9
Screen shapeFlat

Processor

Processor manufacturerIntel
Processor familyIntel® Core™ i3
Processor generation6th gen Intel® Core™ i3
Processor modeli3-6100
Processor cores2
Processor threads4
Processor frequency3.7 GHz
Processor cache3 MB
Processor cache typeL3
Processor socketLGA 1151 (Socket H4)
System bus rate8 GT/s
Thermal Design Power (TDP)51 W
Bus typeDMI3
Maximum number of PCI Express lanes16
PCI Express configurations1x16, 1x8+2x4, 2x8
PCI Express slots version3.0
Processor codeSR2HG
Processor codenameSkylake
Processor lithography14 nm
Processor operating modes64-bit
Processor seriesIntel Core i3-6100 series
Tcase65 °C
Conflict-Free processorYes
Maximum internal memory supported by processor64 GB
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor1333,1600,1866,2133 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Memory channels supported by processorDual
ECC supported by processorYes
Memory voltage supported by processor1.35 V

Memory

Internal memory8 GB
Internal memory typeDDR4-SDRAM
Maximum internal memory16 GB
Memory slots2
Memory form factorDIMM/SO-DIMM

Storage

Total storage capacity1 TB
Storage mediaHDD
Number of storage drives installed1
Number of HDDs installed1
HDD capacity1 TB
Optical drive typeDVD Super Multi
Card reader integratedYes
Compatible memory cardsMMC, Memory Stick (MS), SD

Graphics

Discrete graphics cardYes
Discrete graphics card modelNVIDIA® GeForce® 930MX
Discrete graphics card memory2 GB
Discrete graphics memory typeGDDR3
On-board graphics cardYes
On-board graphics card modelIntel® HD Graphics 530
Maximum on-board graphics card memory1.7 GB
Number of displays supported (on-board graphics)3
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1050 MHz
On-board graphics card DirectX version12.0
On-board graphics card ID0x1912
On-board graphics card OpenGL version4.4

Audio

Built-in speaker(s)Yes
RMS rated power10 W
Built-in microphoneYes

Camera

Built-in cameraYes
Total megapixels1 MP

Network

Wi-FiYes
Wi-Fi standardsWi-Fi 5 (802.11ac)
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s

Ports & interfaces

Ethernet LAN (RJ-45) ports1
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
Thunderbolt 3 ports quantity0
Thunderbolt ports quantity0
HDMI ports quantity2
VGA (D-Sub) ports quantity1
Headphone outputs1
Microphone inYes
DC-in jackYes
Serial ports quantity2

Design

Product colourBlack

Performance

Product typeAll-in-One PC

Software

Operating system installedWindows 10 Home
Operating system architecture64-bit

Processor special features

CPU configuration (max)1
Embedded options availableYes
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Graphics & IMC lithography14 nm
Idle StatesYes
Intel 64Yes
Intel Clear Video TechnologyYes
Intel Enhanced Halt StateYes
Intel Identity Protection Technology version1.00
Intel Secure Key Technology version1.00
Intel Small Business Advantage (SBA) version1.00
Intel Software Guard Extensions (Intel SGX)Yes
Intel Stable Image Platform Program (SIPP)No
Intel Stable Image Platform Program (SIPP) version0.00
Intel TSX-NINo
Intel TSX-NI version0.00
Intel Trusted Execution TechnologyNo
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® InTru™ 3D TechnologyYes
Intel® Insider™Yes
Intel® OS GuardYes
Intel® Quick Sync Video TechnologyYes
Intel® Secure KeyYes
Intel® Small Business Advantage (Intel® SBA)Yes
Intel® Smart CacheYes
Intel® Turbo Boost TechnologyNo
Intel® Wireless Display (Intel® WiDi)Yes
Processor ARK ID90729
Processor package size37.5 x 37.5 mm
Scalability1S
Supported instruction setsSSE4.1, SSE4.2
Thermal Monitoring TechnologiesYes
Thermal solution specificationPCG 2015C

Power

AC adapter power150 W

Weight & dimensions

Width (with stand)581.5 mm
Depth (with stand)221.9 mm
Height (with stand)484.6 mm
Weight (with stand)12.5 kg
Width (without stand)581.5 mm
Depth (without stand)100.5 mm
Height (without stand)406 mm
Package weight13.8 kg

Packaging content

Mouse includedNo
Keyboard includedNo
AC adapter includedYes

Other features

3DNo
Autonomy modeNo
Detachable displayNo
