Lenovo ThinkCentre neo 50a 24 Gen 4

ThinkCentre neo 50a 24 Gen 4

Model ThinkCentre neo 50a 24 Gen 4Part no. 12K9001FMZEAN 196803997316

123 specifications

Display60.5 cm (23.8")
Resolution1920 x 1080 pixels
ProcessorIntel® Core™ i7
Memory16 GB
Storage512 GB
GraphicsIntel Arc A370M

See all specifications

Overview

Display: 60.5 cm (23.8")
Resolution: 1920 x 1080 pixels
Processor: Intel® Core™ i7
Memory: 16 GB
Storage: 512 GB
Graphics: Intel Arc A370M

Brand: Lenovo
Category: All-in-One PCs/Workstations
Model: ThinkCentre neo 50a 24 Gen 4
Part numbers: 12K9001FMZ, 12KA000LUK, 12K7A01KID, 12K9000VMZ
EAN / UPC: 196803997316, 197528481074, 197530716454, 196803993783
Also known as: Lenovo ThinkCentre neo 50a 24 Gen 4 Intel® Core™ i7 i7-13700H 60.5 cm (23.8") 1920 x 1080 pixels All-in-One PC 16 GB DDR5-SDRAM 512 GB SSD Intel Arc A370M Windo

Specifications

123 specifications in 18 groups

Display

Specification	Value
Display diagonal	60.5 cm (23.8")
Display resolution	1920 x 1080 pixels
Touchscreen	No
HD type	Full HD
Native aspect ratio	16:9
Display brightness	250 cd/m²
Panel type	IPS
Anti-glare screen	Yes
Low Blue Light technology	Yes
RGB colour space	NTSC
Colour gamut	72%
Tilt adjustment	Yes
Tilt angle range	-5 - 18°

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	13th gen Intel® Core™ i7
Processor model	i7-13700H
Processor cores	14
Processor threads	20
Processor boost frequency	5 GHz
Performance cores	6
Efficient cores	8
Performance-core Max Turbo Frequency	5 GHz
Efficient-core Max Turbo Frequency	3.7 GHz
Processor cache	24 MB
Processor cache type	Smart Cache
Maximum turbo power	115 W
Processor base power	45 W

Memory

Specification	Value
Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	16 GB
Memory slots	2
Memory slots type	SO-DIMM
Memory clock speed	5200 MHz
Memory layout (slots x size)	1 x 16 GB
Memory form factor	DIMM/SO-DIMM

Storage

Specification	Value
Total storage capacity	512 GB
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
NVMe	Yes
SSD interface	PCI Express 4.0
SSD form factor	M.2
M.2 SSD size	2280 (22 x 80 mm)
Optical drive type	DVD±RW
Card reader integrated	No

Graphics

Specification	Value
Discrete graphics card	Yes
Discrete GPU manufacturer	Intel
Discrete graphics card model	Intel Arc A370M
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR6
On-board GPU manufacturer	Intel
On-board graphics card	Yes
On-board graphics card model	Intel Iris Xe Graphics

Audio

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	6 W
Speakers manufacturer	Harman Kardon
Built-in microphone	Yes
Audio system	HD

Camera

Specification	Value
Built-in camera	Yes
Total megapixels	5 MP

Network

Specification	Value
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller manufacturer	Intel
Wi-Fi standards	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Antenna type	2x2
Ethernet LAN	Yes
Ethernet LAN data rates	100,1000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.2

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 2.0 Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
USB4 Gen 3x2 ports quantity	0
HDMI ports quantity	2
HDMI version	1.4/2.1
Combo headphone/mic port	Yes

Design

Specification	Value
Product colour	Black
Colour name	Raven black
Cable lock slot	Yes
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
VESA mounting	Yes

Performance

Specification	Value
Product type	All-in-One PC
Motherboard chipset	Intel SoC
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
BIOS password	Yes
HDD user password	Yes

Software

Specification	Value
Operating system installed	Windows 11 Pro
Operating system language	English

Power

Specification	Value
AC adapter power	180 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V

Weight & dimensions

Specification	Value
Width (with stand)	541 mm
Depth (with stand)	220 mm
Height (with stand)	482 mm
Weight (with stand)	7.64 kg
Package width	658 mm
Package depth	264 mm
Package height	570 mm
Package weight	11.9 kg

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12192 m

Certificates

Specification	Value
Certification	TÜV Rheinland® Flicker Free TÜV Rheinland Low Blue Light TÜV Rheinland Ultra Low Noise ENERGY STAR 8.0 EPEAT Silver Registered

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR, EPEAT Silver

Packaging content

Specification	Value
Mouse connectivity	Wireless
Mouse included	Yes
Keyboard connectivity	Wireless
Keyboard included	Yes
Keyboard language	UK English
