Vertiv Liebert APS 16-Bay Frame 1-Phase 5kVA with 1 internal Battery String 8-10Y

Vertiv Liebert APS 16-Bay Frame 1-Phase 5kVA with 1 internal Battery String 8-10Y

Model AS2A0NCLMNNX000EAN 767041025460

60 specifications
  • Battery9 VAh
  • Noise65 dB
  • TypeTower
  • Weight189 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
See all specifications

Overview

Battery
9 VAh
Noise
65 dB
Type
Tower
Weight
189 kg
Colour
Black
UPS topology
Double-conversion (Online)
Brand
Vertiv
Model
AS2A0NCLMNNX000
Part number
AS2A0NCLMNNX000
EAN / UPC
767041025460
Also known as
Vertiv Liebert APS 16-Bay Frame 1-Phase 5kVA with 1 internal Battery String 8-10Y

Specifications

60 specifications in 11 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity5 kVA
Output power5000 W
WaveformSine
Input operation voltage (min)140 V
Input operation voltage (max)485 V
Input frequency50/60 Hz
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Output voltage regulation3%
Response time0 ms
Number of input phases1/3
Number of output phases1
Single-phase input voltage supported220,230,240 V
Three-phase input voltage supported380,400,415 V
Efficiency (On-line mode)92%
Power factor0.9
Input power factor0.99
Overload capacity (1 minute)130%
Noise level65 dB

Ports & interfaces

AC outlet typesTerminal
Power plugTerminal
USB portYes
USB 2.0 ports quantity1
Serial ports quantity1

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity9 VAh
Battery voltage12 V
Number of batteries supported12
Number of battery cells1
Typical backup time at full load5 min
Typical backup time at half load13 min
Battery recharge time5 h
Hot-swap batteryYes

Design

Form factorTower
Product colourBlack
Cooling typeActive
Display typeLCD
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 3000 m

Certificates

Compliance certificatesRoHS
CertificationCE

Sustainability

Sustainability certificatesENERGY STAR

Safety regulation & standards

SafetyIEC62040-1:2008 version & UL/cUL

Weight & dimensions

Width440 mm
Depth850 mm
Height970 mm
Weight189 kg

Packaging data

Package width650 mm
Package depth1150 mm
Package height1200 mm
Package weight199 kg

Other features

Output voltage230 V
