Legrand UPS DAKER DK PLUS 5000VA

Legrand UPS DAKER DK PLUS 5000VA

Model UPS DAKER DK PLUS 5000VAPart no. 310173EAN 3414970826954

66 specifications
  • Battery5 Ah
  • Noise50 dB
  • TypeRackmount
  • Weight60 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
See all specifications

Overview

Battery
5 Ah
Noise
50 dB
Type
Rackmount
Weight
60 kg
Colour
Black
UPS topology
Double-conversion (Online)
Brand
Legrand
Model
UPS DAKER DK PLUS 5000VA
Part number
310173
EAN / UPC
3414970826954
Also known as
Legrand Daker DK+ UPS DAKER DK PLUS 5000VA uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 5000 W 11 AC outlet(s)

Specifications

66 specifications in 9 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity5 kVA
Output power5000 W
WaveformSine
Input operation voltage (min)176 V
Input operation voltage (max)280 V
Input frequency47/63 Hz
Output operation voltage (min)228 V
Output operation voltage (max)232 V
Output frequency50/60 Hz
Output voltage regulation1%
Surge energy rating1900 J
Number of input phases1
Number of output phases1
Efficiency94%
Efficiency (ECO mode)97%
Power factor1
Input power factor0.99
Output power factor1
Crest factor3:1
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)3%
Input current Total Harmonic Distortion (THD)3%
Noise level50 dB
Management protocolsNetwork management,Simple Network Management Protocol (SNMP)
Potential-free outputNo
Auto shut-offNo
Detachable power cordYes
Power source typeAC

Ports & interfaces

AC outlet typesC13 coupler, C19 coupler
Power plugHardwire
AC outlets quantity11 AC outlet(s)
USB portYes
Serial interfaceYes
Serial interface typeRS-232

Battery

Battery capacity5 Ah
Battery voltage12 V
Number of batteries supported20

Design

Form factorRackmount
Product colourBlack
Rack capacity4U
Display typeLCD
LED indicatorsStatus
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 95%

Certificates

CertificationEN 62040-1, EN 62040-2, EN 62040-3

Weight & dimensions

Width196 mm
Depth680 mm
Height440 mm
Weight60 kg

Packaging data

Package width196 mm
Package depth58.6 mm
Package height440 mm
Package weight56.1 kg

Logistics data

Products per pallet2 pc(s)
Harmonized System (HS) code85078000
Pallet net height43 cm
Pallet net length100 cm
Pallet net weight118.2 kg
Pallet net width120 cm
Master (outer) case width560 mm
Master (outer) case length872 mm
Master (outer) case height316 mm
Master (outer) case gross weight59.1 kg
Products per master (outer) case1 pc(s)
