Legrand UPS DAKER DK PLUS 2000VA

Legrand UPS DAKER DK PLUS 2000VA

Model UPS DAKER DK PLUS 2000VAPart no. 310171EAN 3414970826930

65 specifications
  • Battery7.2 Ah
  • Noise50 dB
  • TypeRackmount
  • Weight29.5 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
See all specifications

Overview

Battery
7.2 Ah
Noise
50 dB
Type
Rackmount
Weight
29.5 kg
Colour
Black
UPS topology
Double-conversion (Online)
Brand
Legrand
Model
UPS DAKER DK PLUS 2000VA
Part number
310171
EAN / UPC
3414970826930
Also known as
Legrand Daker DK+ UPS DAKER DK PLUS 2000VA uninterruptible power supply (UPS) Double-conversion (Online) 2 kVA 1800 W 6 AC outlet(s)

Specifications

65 specifications in 9 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity2 kVA
Output power1800 W
WaveformSine
Input operation voltage (min)176 V
Input operation voltage (max)280 V
Input frequency47/63 Hz
Output operation voltage (min)228 V
Output operation voltage (max)232 V
Output frequency50/60 Hz
Output voltage regulation1%
Surge energy rating1530 J
Number of input phases1
Number of output phases1
Efficiency91%
Efficiency (ECO mode)97%
Input power factor0.99
Output power factor0.9
Crest factor3:1
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)3%
Input current Total Harmonic Distortion (THD)3%
Noise level50 dB
Management protocolsNetwork management,Simple Network Management Protocol (SNMP)
Potential-free outputNo
Auto shut-offNo
Power source typeAC

Ports & interfaces

AC outlet typesC13 coupler
Power plugC14 coupler
AC outlets quantity6 AC outlet(s)
USB portYes
Serial interfaceYes
Serial interface typeRS-232

Battery

Battery capacity7.2 Ah
Battery voltage12 V
Number of batteries supported6
Battery recharge time4 h

Design

Form factorRackmount
Product colourBlack
Rack capacity2U
Display typeLCD
LED indicatorsStatus
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 95%

Certificates

CertificationEN 62040-1, EN 62040-2, EN 62040-3

Weight & dimensions

Width88 mm
Depth600 mm
Height440 mm
Weight29.5 kg

Packaging data

Package width88 mm
Package depth23.2 mm
Package height440 mm
Package weight24.7 kg

Logistics data

Products per pallet12 pc(s)
Harmonized System (HS) code85078000
Pallet net height151.5 cm
Pallet net length100 cm
Pallet net weight312 kg
Pallet net width120 cm
Master (outer) case width560 mm
Master (outer) case length710 mm
Master (outer) case height230 mm
Master (outer) case gross weight26 kg
Products per master (outer) case1 pc(s)
