DH-PFM3350-100 uninterruptible power supply (UPS) Line-Interactive 1 kVA
Dahua Technology

DH-PFM3350-100 uninterruptible power supply (UPS) Line-Interactive 1 kVA

600 W 2 AC outlet(s)

Model DH-PFM3350-100

61 specifications
  • Battery9 Ah
  • TypeDesktop
  • Weight4.9 kg
  • ColourBlack
  • UPS topologyLine-Interactive
  • AC outlet typesType F
See all specifications

Overview

Battery
9 Ah
Type
Desktop
Weight
4.9 kg
Colour
Black
UPS topology
Line-Interactive
AC outlet types
Type F
Brand
Dahua Technology
Model
DH-PFM3350-100
Part number
DH-PFM3350-100
Also known as
Dahua Technology DH-PFM3350-100 uninterruptible power supply (UPS) Line-Interactive 1 kVA 600 W 2 AC outlet(s)

Specifications

61 specifications in 11 groups

Features

UPS topologyLine-Interactive
Output power capacity1 kVA
Output power600 W
WaveformPure sine
Input operation voltage (min)170 V
Input operation voltage (max)280 V
Input frequency50/60 Hz
Output operation voltage (min)170 V
Output operation voltage (max)280 V
Output frequency50/60 Hz
Automatic Voltage Regulation (AVR)Yes
Maximum current4.8 A
Response time4 ms
Number of input phases1
Number of output phases1
Power factor0.6
Input power factor0.6
Power protection featuresBattery discharge, Overcharge, Overdischarge, Overload
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm

Ports & interfaces

AC outlet typesType F
Power plugType A
AC outlets quantity2 AC outlet(s)

Battery

Battery technologyLead-Acid
Battery capacity9 Ah
Battery voltage13.7 V
Number of batteries included1 pc(s)
Number of batteries supported1
Number of battery cells1
Battery recharge time4 h
Charging current1 A
Hot-swap batteryNo

Design

Form factorDesktop
Product colourBlack
Housing materialPlastic
Cable length1.2 m
Built-in fanNo
LED indicatorsAlarm, Battery replacement, Fault, Status, Yes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 55 °C
Operating relative humidity (H-H)0 - 90%
Storage relative humidity (H-H)0 - 90%

Packaging content

Batteries includedYes
Cables includedInput power cable

Certificates

Compliance certificatesCE, Low Voltage Directive (LVD), Electromagnetic Compatibility (EMC)
Recycling codesLead (Lead–acid battery)
CertificationCE LVD: EN IEC 62040-1: 2019+A11: 2021; CE EMC: EN 62040-2: 2006; EN IEC 62040-2: 2018; EN IEC 61000-3-2: 2019+A1: 2021+A2: 2024; EN 61000-3-3: 2013+A1: 2019+A2: 2021

Power

Input current (max)4.8 A

Technical details

Dangerous goodsYes
Removable batteryNo

Weight & dimensions

Width101.5 mm
Depth298.4 mm
Height142.2 mm
Weight4.9 kg
Extended battery module width10.2 cm
Extended battery module depth14.2 cm
Extended battery module height29.8 cm

Packaging data

Package width142 mm
Package depth342 mm
Package height223 mm
Package weight5.1 kg
