LCD Line-Interactive USV 1150VA/1150WRack 1U, AVR, , Outlets (8) IEC, RJ45 Lan Protection, RS232, USB (HID) EPO, Built in Cloud Interface, Smart-Slot
CyberPower

LCD Line-Interactive USV 1150VA/1150WRack 1U, AVR, , Outlets (8) IEC, RJ45 Lan Protection, RS232, USB (HID) EPO, Built in Cloud Interface, Smart-Slot

Model PR1150ERM1UCEAN 4711027797380

66 specifications
  • TypeRackmount
  • Weight18.3 kg
  • ColourBlack, Silver
  • UPS topologyLine-Interactive
  • AC outlet typesC13 coupler
  • Battery replacement accessibilityEnd-user
See all specifications

Overview

Type
Rackmount
Weight
18.3 kg
Colour
Black, Silver
UPS topology
Line-Interactive
AC outlet types
C13 coupler
Battery replacement accessibility
End-user
Brand
CyberPower
Model
PR1150ERM1UC
Part number
PR1150ERM1UC
EAN / UPC
4711027797380
Also known as
CyberPower LCD Line-Interactive USV 1150VA/1150WRack 1U, AVR, , Outlets (8) IEC, RJ45 Lan Protection, RS232, USB (HID) EPO, Built in Cloud Interface, Smart-Slot

Specifications

66 specifications in 10 groups

Features

UPS topologyLine-Interactive
Output power capacity1.15 kVA
Output power1150 W
WaveformPure sine
Input operation voltage (min)200 V
Input operation voltage (max)240 V
Input frequency50/60 Hz
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Output voltage regulation5%
Automatic Voltage Regulation (AVR)Yes
Maximum current10 A
Surge energy rating2720 J
Heat dissipation61 BTU/h
Output power factor1
Emergency Power Off (EPO)Yes
EMI/RFI noise filteringYes
Surge protectionYes
Power protection featuresOverload
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Overload alarm

Ports & interfaces

AC outlet typesC13 coupler
Power plugC14 coupler
AC outlets quantity6 AC outlet(s)
USB portYes
USB port typeUSB Type-B
RS-232 ports1
Ethernet LAN (RJ-45) ports1
Emergency Power Off (EPO) connectorYes

Battery

Battery replacement accessibilityEnd-user
Battery technologySealed Lead Acid (VRLA)
Number of batteries supported1
Typical backup time at full load3.6 min
Typical backup time at half load11.7 min
Battery recharge time3 h
Hot-swap batteryYes
Replacement battery cartridgeRBP0206

Design

Form factorRackmount
Product colourBlack, Silver
Housing materialMetal
Rack capacity1U
Cable length1.8 m
Built-in fanNo
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Packaging content

Rack mount kitYes
Cables includedInput power cable, USB cable
ManualYes

Certificates

Compliance certificatesCE, Federal Communications Commission (FCC), VCCI, RoHS

Weight & dimensions

Width433 mm
Depth554 mm
Height44 mm
Weight18.3 kg

Packaging data

Screws includedYes
Package width560 mm
Package depth710 mm
Package height160 mm
Package weight22.8 kg

Other features

BypassGreenPower UPS
