OLS2000EA uninterruptible power supply (UPS) Double-conversion (Online) 2 kVA
1800 W 4 AC outlet(s)
Model OLS2000EAEAN 4711027790114
69 specifications
- TypeTower
- Weight16.9 kg
- ColourBlack
- UPS topologyDouble-conversion (Online)
- AC outlet typesC13 coupler
- Battery technologySealed Lead Acid (VRLA)
Overview
- Type
- Tower
- Weight
- 16.9 kg
- Colour
- Black
- UPS topology
- Double-conversion (Online)
- AC outlet types
- C13 coupler
- Battery technology
- Sealed Lead Acid (VRLA)
- Brand
- CyberPower
- Model
- OLS2000EA
- Part number
- OLS2000EA
- EAN / UPC
- 4711027790114
- Also known as
- CyberPower OLS2000EA uninterruptible power supply (UPS) Double-conversion (Online) 2 kVA 1800 W 4 AC outlet(s)
Specifications
69 specifications in 12 groups
Features
| Specification | Value |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 2 kVA |
| Output power | 1800 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 200 V |
| Input operation voltage (max) | 300 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 208 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Maximum current | 9 A |
| Surge energy rating | 345 J |
| Response time | 0 ms |
| Heat dissipation | 682 BTU/h |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency (ECO mode) | 95% |
| Power factor | 0.9 |
| Input power factor | 0.98 |
| Crest factor | 3:1 |
| ECO mode | Yes |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| EMI/RFI noise filtering | Yes |
| Surge protection | Yes |
| Power protection features | Overload |
| Audible alarm(s) | Yes |
| Audible alarm modes | Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm |
| Detachable power cord | Yes |
| Power source type | AC |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlet types | C13 coupler |
| Power plug | C14 coupler |
| AC outlets quantity | 4 AC outlet(s) |
| USB port | Yes |
| Emergency Power Off (EPO) connector | Yes |
Battery
| Specification | Value |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
| Number of batteries supported | 3 |
| Typical backup time at full load | 3.8 min |
| Typical backup time at half load | 13.1 min |
| Battery recharge time | 4 h |
| Charging current | 1.5 A |
Design
| Specification | Value |
|---|---|
| Form factor | Tower |
| Product colour | Black |
| Housing material | Metal |
| Cable length | 1.5 m |
| Cooling type | Active |
| Control type | Buttons |
| Display type | LCD |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 1500 m |
| Non-operating altitude | 0 - 1500 m |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB cable |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
| Certification | RoHS |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 151 mm |
| Depth | 394 mm |
| Height | 225 mm |
| Weight | 16.9 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 241 mm |
| Package depth | 510 mm |
| Package height | 313 mm |
| Package weight | 19.8 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8504408590 |
| Country of origin | China |
Other features
| Specification | Value |
|---|---|
| Nominal input voltage | 230 V |
