Online S Series OL750RM uninterruptible power supply (UPS) Double-conversion (Online) 1.5 kVA
600 W 8 AC outlet(s)
Model OL750RMEAN 649532938742
53 specifications
- Battery7 Ah
- Noise42.8 dB
- TypeRackmount
- Weight16.2 kg
- ColourSilver
- UPS topologyDouble-conversion (Online)
Overview
- Battery
- 7 Ah
- Noise
- 42.8 dB
- Type
- Rackmount
- Weight
- 16.2 kg
- Colour
- Silver
- UPS topology
- Double-conversion (Online)
- Brand
- CyberPower
- Model
- OL750RM
- Part number
- OL750RM
- EAN / UPC
- 649532938742
- Also known as
- CyberPower Online S Series OL750RM uninterruptible power supply (UPS) Double-conversion (Online) 1.5 kVA 600 W 8 AC outlet(s)
Specifications
53 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 1.5 kVA |
| Output power | 600 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 100 V |
| Input operation voltage (max) | 125 V |
| Input frequency | 40 - 70 Hz |
| Output frequency | 50/60 Hz |
| Surge energy rating | 710 J |
| Heat dissipation | 174 BTU/h |
| Number of input phases | 1 |
| Efficiency (ECO mode) | 96% |
| Power factor | 0.8 |
| Input power factor | 0.99 |
| Output power factor | 0.8 |
| Crest factor | 3:1 |
| ECO mode | Yes |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Input current Total Harmonic Distortion (THD) | 5% |
| EMI/RFI noise filtering | Yes |
| Noise level | 42.8 dB |
| Audible alarm(s) | Yes |
| Audible alarm modes | Overload alarm, Alarm when on battery, Low battery alarm, Fault |
Ports & interfaces
| Specification | Value |
|---|---|
| AC outlet types | NEMA 5-15P |
| Power plug | NEMA 5-15P |
| AC outlets quantity | 8 AC outlet(s) |
| USB port | Yes |
| Serial interface | Yes |
| Emergency Power Off (EPO) connector | Yes |
Battery
| Specification | Value |
|---|---|
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery capacity | 7 Ah |
| Battery voltage | 12 V |
| Battery recharge time | 4 h |
Design
| Specification | Value |
|---|---|
| Form factor | Rackmount |
| Product colour | Silver |
| Housing material | Metal |
| Rack capacity | 2U |
| Cable length | 3 m |
| LED indicators | Power |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 0.9% |
| Storage relative humidity (H-H) | 0 - 0.95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 14999 m |
Packaging content
| Specification | Value |
|---|---|
| Rack mount kit | Yes |
| Cables included | USB cable |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS, UL, Federal Communications Commission (FCC) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 433 mm |
| Depth | 374 mm |
| Height | 86 mm |
| Weight | 16.2 kg |
Energy efficiency
ENERGY STAR certified
Uninterruptible power supplies · model OL750RM · certified Jan 3, 2025 · United States
| Measurement | Value |
|---|---|
| Average efficiency | 91.4 % |
