CDP UPO11-3RTAXi 3000VA/3000W Online UPS 2U 19' RT PF 1.0, LCD UL, FCC, CE 220 Vac

CDP UPO11-3RTAXi 3000VA/3000W Online UPS 2U 19' RT PF 1.0, LCD UL, FCC, CE 220 Vac

Model UPO11-3RTAXIEAN 879071004114

72 specifications
  • Battery9 Ah
  • Noise50 dB
  • TypeRackmount/Tower
  • Weight32.7 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
See all specifications

Overview

Battery
9 Ah
Noise
50 dB
Type
Rackmount/Tower
Weight
32.7 kg
Colour
Black
UPS topology
Double-conversion (Online)
Brand
CDP
Model
UPO11-3RTAXI
Part number
UPO11-3RTAXI
EAN / UPC
879071004114
Also known as
CDP UPO11-3RTAXi 3000VA/3000W Online UPS 2U 19' RT PF 1.0, LCD UL, FCC, CE 220 Vac

Specifications

72 specifications in 9 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity3 kVA
Output power3000 W
WaveformPure sine
Input operation voltage (min)110 V
Input operation voltage (max)300 V
Input frequency40 - 70 Hz
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Surge energy rating844 J
Number of input phases1
Number of output phases1
Efficiency (On-line mode)90%
Efficiency (ECO mode)98%
Power factor1
Input power factor0.99
Output power factor1
Crest factor3:1
ECO modeYes
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)4%
Input current Total Harmonic Distortion (THD)3%
EMI/RFI noise filteringYes
Noise level50 dB
Surge protectionYes
Power protection featuresOverload, Short circuit
Audible alarm(s)Yes

Ports & interfaces

AC outlet typesC13 coupler, C19 coupler
AC outlets quantity8 AC outlet(s)
USB portYes
USB 2.0 ports quantity1
RS-232 ports1
Emergency Power Off (EPO) connectorYes

Battery

Battery technologyLead-Acid
Battery capacity9 Ah
Battery voltage12 V
Number of batteries supported6
Typical backup time at full load7 min
Typical backup time at half load15 min
Battery recharge time4 h
Cold startYes

Design

Form factorRackmount/Tower
Product colourBlack
Housing materialMetal
Rack capacity2U
Cable length1.5 m
Cooling typeActive
Built-in fanYes
Display typeLCD
LED indicatorsYes
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 60 °C
Operating relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m

Certificates

CertificationNOM, ISO9001-2015, ISO14001, RETIE, TÜV, UL

Weight & dimensions

Width600 mm
Depth760 mm
Height200 mm
Weight32.7 kg

Packaging data

Package weight32.2 kg

Logistics data

Master (outer) case net weight32.7 kg
Pallet gross height2.17 m
Pallet gross length120 cm
Pallet gross weight451.1 kg
Pallet gross width100 cm
Master (outer) case width600 mm
Master (outer) case length760 mm
Master (outer) case height200 mm
Master (outer) case gross weight32.2 kg
Products per master (outer) case1 pc(s)
