APC Symmetra PX 100kW

APC Symmetra PX 100kW

Model Symmetra PX 100kWPart no. SY100K100F-NB

40 specifications
  • Noise67 dB
  • Weight571 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • SmartSlotYes
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Noise
67 dB
Weight
571 kg
Colour
Black
UPS topology
Double-conversion (Online)
SmartSlot
Yes
Operating temperature (T-T)
0 - 40 °C
Brand
APC
Model
Symmetra PX 100kW
Part number
SY100K100F-NB
Also known as
APC Symmetra PX 100kW uninterruptible power supply (UPS) Double-conversion (Online) 100 kVA 100000 W

Specifications

40 specifications in 9 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity100 kVA
Output power100000 W
WaveformSine
Input operation voltage (min)177 V
Input operation voltage (max)239 V
Input frequency40 - 70 Hz
Output operation voltage (min)120 V
Output operation voltage (max)208 V
Output frequency60 Hz
Output frequency regulation57 - 63 Hz
Maximum current332 A
Input power factor0.98
Output voltage Total Harmonic Distortion (THD)2%
Input current Total Harmonic Distortion (THD)5%
Noise level67 dB
Audible alarm(s)Yes
Web-based managementYes
Audible alarm modesAlarm when on battery, Low battery alarm

Ports & interfaces

SmartSlotYes

Battery

Automatic battery testYes

Design

Product colourBlack
Display typeLCD
LED indicatorsStatus

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 999.9 m

Certificates

Compliance certificatesRoHS
CertificationREACH, CE Mark, CSA C22.2 No.107.3-05, EN/IEC 62040-3, Eurobat General Purpose, FCC Part 15 Class A, ISO 14001, ISO 9001, UL 1778

Sustainability

Sustainability certificatesENERGY STAR

Weight & dimensions

Width600 mm
Depth1070 mm
Height2011 mm
Weight571 kg

Packaging data

Package width848 mm
Package depth1210 mm
Package height2140 mm
Package weight298.9 kg
