APC Symmetra LX 16KVA on-line

APC Symmetra LX 16KVA on-line

Model Symmetra LX 16KVA on-linePart no. SYA16K16RMIEAN 8592978122362

53 specifications
  • ConnectivityDB-9 RS-232, Smart-Slot
  • Weight286.8 kg
  • ColourBlack, Silver
  • Output power capacity16 kVA
  • AC outlet typesIEC 60320
  • Battery replacement accessibilityEnd-user
See all specifications

Overview

Connectivity
DB-9 RS-232, Smart-Slot
Weight
286.8 kg
Colour
Black, Silver
Output power capacity
16 kVA
AC outlet types
IEC 60320
Battery replacement accessibility
End-user
Brand
APC
Model
Symmetra LX 16KVA on-line
Part number
SYA16K16RMI
EAN / UPC
8592978122362, 731304218913, 3606485318738, 5054444332550 +3 more
Also known as
APC Symmetra LX 16kVA Scalable to 16kVA N+1 Rack-mount, 220/230/240V or 380/400/415V

Specifications

53 specifications in 12 groups

Features

Output power capacity16 kVA
Output power11200 W
WaveformSine
Number of input phases1
Number of output phases1
Single-phase input voltage supported240,220 V
Three-phase input voltage supported220,380,400,415 V
Emergency Power Off (EPO)Yes
Audible alarm(s)Yes

Ports & interfaces

AC outlet typesIEC 60320

Battery

Battery replacement accessibilityEnd-user
Typical backup time at full load7.5 min
Typical backup time at half load20.3 min
Battery recharge time3 h
Replacement battery cartridgeSYBT5

Design

Product colourBlack, Silver
CompatibilityC-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 55024, EN 60950, GOST, IEC 60950, VDE

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m

Certificates

Compliance certificatesRoHS, REACH, WEEE
Waste Electrical and Electronic Equipment (WEEE) complianceYes
CertificationC-Tick; CE; GOST; VDE

Power

Input current (max)73 A

Technical details

Packaging recycled materialsRecycled cardboard
Preferred mounting positionlower
Packaging without single use plasticNo
SCIP number2d54512b-134b-4bf3-ab6e-849ecf1e3919
Sustainable packagingNo
Take-back systemNo

Weight & dimensions

Width472 mm
Depth688 mm
Height838 mm
Weight286.8 kg

Packaging data

Package weight340.4 kg

Logistics data

Customs product code (TARIC)8504409590
Harmonized System (HS) code85078000
Total carbon footprint (kg of CO2e)45918.3243238434
Country of originPhilippines

Other features

Battery typeLead-Acid
InterfaceDB-9 RS-232, Smart-Slot
Output connections(1) Hard Wire 3-wire (H N + G) (8) IEC 320 C13 (10) IEC 320 C19
Input connection typeHard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G)
Dimensions (WxDxH)472 x 688 x 838 mm
Mountingfront
Nominal input voltage230 V
Output connection typehard wire 3-wire (H N + E) for 1 zone(s); 8 IEC 60320C13; 10 IEC 60320C19
Output voltage220 V
Output voltage note220: 230, 240
Package dimensions (WxDxH)599 x 997 x 1054 mm
I/O ports(1) Hard Wire 3-wire (H N + G) (8) IEC 320 C13 (10) IEC 320 C19 Hard Wire 3 wire (1PH+N+G) Hard Wire 5-wire (3PH + N + G)
