APC Symmetra PX 48kW All-in-One, without Batteries

APC Symmetra PX 48kW All-in-One, without Batteries

400V

Model SY48K48H-PDNB

40 specifications
  • Noise61 dB
  • Weight397 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
  • Power plugTerminal
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Noise
61 dB
Weight
397 kg
Colour
Black
UPS topology
Double-conversion (Online)
Power plug
Terminal
Operating temperature (T-T)
0 - 40 °C
Brand
APC
Model
SY48K48H-PDNB
Part number
SY48K48H-PDNB
Also known as
APC Symmetra PX 48kW All-in-One, without Batteries, 400V

Specifications

40 specifications in 9 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity48 kVA
Output power48000 W
WaveformSine
Input operation voltage (min)340 V
Input operation voltage (max)477 V
Input frequency40 - 70 Hz
Output operation voltage (min)380 V
Output operation voltage (max)415 V
Output frequency50/60 Hz
Maximum current98 A
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)2%
Input current Total Harmonic Distortion (THD)5%
Noise level61 dB
Audible alarm(s)Yes
Web-based managementYes
Audible alarm modesAlarm when on battery, Low battery alarm

Ports & interfaces

Power plugTerminal
SmartSlotYes

Design

Product colourBlack
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Non-operating altitude0 - 15000 m

Packaging content

Management card includedYes

Certificates

CertificationEN 50091-1, EN/IEC 62040-1-1, EN/IEC 62040-3, FCC Part 15 Class A, ISO 14001, ISO 9001, VFI-SS-111

Weight & dimensions

Width600 mm
Depth1070 mm
Height1991 mm
Weight397 kg

Packaging data

Service includedStart-Up Service
Package width848 mm
Package depth1210 mm
Package height2140 mm
Package weight430 kg

Other features

Packaging contentNetwork Management Card, Start-Up Servic
