APC SUA1000RMI1U + WBEXTWAR3YR-SP-03

APC SUA1000RMI1U + WBEXTWAR3YR-SP-03

Model SUA1000RMI1U + WBEXTWAR3YR-SP-03

46 specifications
  • Noise55 dB
  • TypeRackmount
  • Weight21.8 kg
  • ColourBlack
  • UPS topologyLine-Interactive
  • AC outlet typesC13 coupler
See all specifications

Overview

Noise
55 dB
Type
Rackmount
Weight
21.8 kg
Colour
Black
UPS topology
Line-Interactive
AC outlet types
C13 coupler
Brand
APC
Model
SUA1000RMI1U + WBEXTWAR3YR-SP-03
Part number
SUA1000RMI1U + WBEXTWAR3YR-SP-03
Also known as
APC SUA1000RMI1U + WBEXTWAR3YR-SP-03 uninterruptible power supply (UPS) Line-Interactive 1 kVA 640 W 6 AC outlet(s)

Specifications

46 specifications in 8 groups

Features

UPS topologyLine-Interactive
Output power capacity1 kVA
Output power640 W
WaveformSine
Input operation voltage (min)151 V
Input operation voltage (max)302 V
Input frequency47/63 Hz
Output operation voltage (min)230 V
Output operation voltage (max)230 V
Output frequency regulation47 - 63 Hz
Output voltage regulation5%
Automatic Voltage Regulation (AVR)Yes
Surge energy rating480 J
Noise level55 dB
Surge protectionYes
Audible alarm(s)Yes

Ports & interfaces

AC outlet typesC13 coupler
Power plugC14 coupler
AC outlets quantity6 AC outlet(s)
Number of output IEC jumpers2
USB 2.0 ports quantity1
RS-232 ports1

Battery

Battery technologySealed Lead Acid (VRLA)
Typical backup time at full load5.4 min
Typical backup time at half load14.5 min
Battery recharge time2 h

Design

Form factorRackmount
Product colourBlack
Rack capacity1U
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Certificates

Compliance certificatesRoHS
CertificationC-tick, CE, EN 50091-1, EN 50091-2, GOST, VDE

Weight & dimensions

Width432 mm
Depth660 mm
Height44 mm
Weight21.8 kg

Packaging data

Package width559 mm
Package depth775 mm
Package height191 mm
Package weight25.4 kg
