APC Smart-UPS On-Line, 5kVA, Rackmount 3U

APC Smart-UPS On-Line, 5kVA, Rackmount 3U

208V/230V, Hard wire 3-wire(2PH+G)+3-wire(H+N+E)+3-wire(H+N+G) outlets, Network Card+SmartSlot, W/ rail kit

Model SRT5KRMXLW-HWEAN 731304301516

65 specifications
  • Battery845 VAh
  • Noise55 dB
  • TypeRackmount
  • Weight55.8 kg
  • ColourBlack
  • UPS topologyDouble-conversion (Online)
See all specifications

Overview

Battery
845 VAh
Noise
55 dB
Type
Rackmount
Weight
55.8 kg
Colour
Black
UPS topology
Double-conversion (Online)
Brand
APC
Model
SRT5KRMXLW-HW
Part number
SRT5KRMXLW-HW
EAN / UPC
731304301516
Also known as
APC Smart-UPS On-Line, 5kVA, Rackmount 3U, 208V/230V, Hard wire 3-wire(2PH+G)+3-wire(H+N+E)+3-wire(H+N+G) outlets, Network Card+SmartSlot, W/ rail kit

Specifications

65 specifications in 12 groups

Features

UPS topologyDouble-conversion (Online)
Output power capacity5 kVA
Output power4500 W
WaveformSine
Input operation voltage (min)100 V
Input operation voltage (max)275 V
Input frequency40 - 70 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Output frequency regulation50/60 Hz
Surge energy rating480 J
Efficiency93.8%
Crest factor3:1
Emergency Power Off (EPO)Yes
Noise level55 dB
Surge protectionYes
Audible alarm(s)Yes
Auto-restartYes

Ports & interfaces

AC outlet typesHard Wire 3-wire (2PH + G)
Power plugHardwire
USB portYes
Serial interfaceYes
Serial interface typeRJ-45
SmartSlotYes
SmartConnect portNo

Battery

Battery technologySealed Lead Acid (VRLA)
Battery capacity845 VAh
Number of batteries supported1
Typical backup time at full load4 min
Typical backup time at half load11.8 min
Battery life (max)5 year(s)
Battery recharge time1.5 h
Hot-swap batteryYes
Automatic battery testYes
Cold startYes

Design

Form factorRackmount
Product colourBlack
Rack capacity3U
Display typeLCD
LED indicatorsStatus
International Protection (IP) codeIP20

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Packaging content

Management card includedYes

Certificates

Compliance certificatesRoHS
CertificationREACH, CE, CE Mark, CSA C22.2 No.107.3-05, EAC, EN/IEC 62040-1, EN/IEC 62040-2, FCC Part 15 Class A, IRAM, NOM, RCM, UL

Sustainability

Sustainability certificatesENERGY STAR

Weight & dimensions

Width432 mm
Depth719 mm
Height130 mm
Weight55.8 kg

Packaging data

Package width610 mm
Package depth960 mm
Package height330 mm
Package weight68 kg

Logistics data

Products per pallet6 pc(s)
Harmonized System (HS) code85078000
Total carbon footprint (kg of CO2e)8442.38

Other features

Number of phases3
Battery typeAPCRBC140
Output connections1x Hard Wire 3-wire (2PH + G) 1x Hard Wire 3-wire (H N + G)

Energy efficiency

ENERGY STAR certified

Uninterruptible power supplies · model SRT5KRMXLW-HW · certified Feb 28, 2019 · United States, Canada

Average efficiency94.3 %
