APC SMX3KR2UNCX145 uninterruptible power supply (UPS) Line-Interactive 2.88 kVA

APC SMX3KR2UNCX145 uninterruptible power supply (UPS) Line-Interactive 2.88 kVA

2700 W 5 AC outlet(s)

Model SMX3KR2UNCX145EAN 731304402800

55 specifications
  • Noise55 dB
  • TypeRackmount/Tower
  • Weight38.4 kg
  • ColourBlack
  • UPS topologyLine-Interactive
  • Power plugNEMA L5-30P
See all specifications

Overview

Noise
55 dB
Type
Rackmount/Tower
Weight
38.4 kg
Colour
Black
UPS topology
Line-Interactive
Power plug
NEMA L5-30P
Brand
APC
Model
SMX3KR2UNCX145
Part number
SMX3KR2UNCX145
EAN / UPC
731304402800
Also known as
APC SMX3KR2UNCX145 uninterruptible power supply (UPS) Line-Interactive 2.88 kVA 2700 W 5 AC outlet(s)

Specifications

55 specifications in 10 groups

Features

UPS topologyLine-Interactive
Output power capacity2.88 kVA
Output power2700 W
WaveformSine
Input operation voltage (min)70 V
Input operation voltage (max)153 V
Input frequency50/60 Hz
Output operation voltage (min)100 V
Output operation voltage (max)127 V
Output frequency50/60 Hz
Maximum current15 A
Surge energy rating540 J
Response time4 ms
Emergency Power Off (EPO)Yes
Noise level55 dB
Audible alarm(s)Yes
Audible alarm modesLow battery alarm
Detachable power cordNo

Ports & interfaces

AC outlet typesNEMA 5-15R, NEMA 5–20R, NEMA L5-30R
Power plugNEMA L5-30P
AC outlets quantity5 AC outlet(s)
USB portYes
USB 2.0 ports quantity3
USB port typeUSB Type-A/USB Type-B
Serial interfaceYes
Serial interface typeRJ-45
Ethernet LAN (RJ-45) ports1

Battery

Battery technologySealed Lead Acid (VRLA)
Battery life (max)5 year(s)
Battery recharge time3 h

Design

Form factorRackmount/Tower
Product colourBlack
Rack capacity2U
Cable length3.05 m
Control typeButtons
Display typeLED
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3048 m
Non-operating altitude0 - 15240 m

Packaging content

ManualYes

Certificates

Compliance certificatesRoHS, WEEE
CertificationRoHS, WEEE, BSMI, CSA, NOM, TÜV, VCCI Class A

Weight & dimensions

Width432 mm
Depth667 mm
Height85 mm
Weight38.4 kg

Packaging data

Package width869 mm
Package depth596 mm
Package height243 mm
Package weight45.3 kg

Logistics data

Warranty period3 year(s)
