APC SMX3000RMHV2UNC + WBEXTWAR3YR-SP-05

APC SMX3000RMHV2UNC + WBEXTWAR3YR-SP-05

Model SMX3000RMHV2UNC + WBEXTWAR3YR-SP-05

53 specifications
  • Noise55 dB
  • TypeRackmount/Tower
  • Weight37.3 kg
  • ColourBlack
  • UPS topologyLine-Interactive
  • AC outlet typesC13 coupler, C19 coupler
See all specifications

Overview

Noise
55 dB
Type
Rackmount/Tower
Weight
37.3 kg
Colour
Black
UPS topology
Line-Interactive
AC outlet types
C13 coupler, C19 coupler
Brand
APC
Model
SMX3000RMHV2UNC + WBEXTWAR3YR-SP-05
Part number
SMX3000RMHV2UNC + WBEXTWAR3YR-SP-05
Also known as
APC SMX3000RMHV2UNC + WBEXTWAR3YR-SP-05 uninterruptible power supply (UPS) Line-Interactive 3 kVA 2700 W 9 AC outlet(s)

Specifications

53 specifications in 9 groups

Features

UPS topologyLine-Interactive
Output power capacity3 kVA
Output power2700 W
WaveformSine
Input operation voltage (min)140 V
Input operation voltage (max)280 V
Input frequency47/63 Hz
Output operation voltage (min)208 V
Output operation voltage (max)240 V
Output frequency regulation47 - 63 Hz
Automatic Voltage Regulation (AVR)Yes
Surge energy rating645 J
Efficiency98.5%
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)5%
Noise level55 dB
Power protection featuresOverload
Audible alarm(s)Yes
Auto-restartYes

Ports & interfaces

AC outlet typesC13 coupler, C19 coupler
AC outlets quantity9 AC outlet(s)
Number of output IEC jumpers2
RS-232 ports1
Serial ports quantity1

Battery

Battery technologySealed Lead Acid (VRLA)
Typical backup time at full load6.25 min
Typical backup time at half load18 min
Battery recharge time3 h
Hot-swap batteryYes
Automatic battery testYes

Design

Form factorRackmount/Tower
Product colourBlack
Rack capacity2U
Cable length2.44 m
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Certificates

Compliance certificatesRoHS
CertificationC-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 60950, FCC Part 15 Class A, GOST, IRAM, UL 1778, VDE

Weight & dimensions

Width432 mm
Depth667 mm
Height85 mm
Weight37.3 kg

Packaging data

Package width596 mm
Package depth869 mm
Package height243 mm
Package weight45.4 kg

Other features

Number of phases1
