APC SMX2200RMLVUS uninterruptible power supply (UPS) Line-Interactive 2.2 kVA

APC SMX2200RMLVUS uninterruptible power supply (UPS) Line-Interactive 2.2 kVA

1980 W 8 AC outlet(s)

Model SMX2200RMLVUSEAN 731304340379

63 specifications
  • Noise55 dB
  • TypeRackmount/Tower
  • Weight38.5 kg
  • ColourBlack
  • UPS topologyLine-Interactive
  • AC outlet typesNEMA 5-15R, NEMA 5–20R
See all specifications

Overview

Noise
55 dB
Type
Rackmount/Tower
Weight
38.5 kg
Colour
Black
UPS topology
Line-Interactive
AC outlet types
NEMA 5-15R, NEMA 5–20R
Brand
APC
Model
SMX2200RMLVUS
Part number
SMX2200RMLVUS
EAN / UPC
731304340379
Also known as
APC SMX2200RMLVUS uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1980 W 8 AC outlet(s)

Specifications

63 specifications in 11 groups

Features

UPS topologyLine-Interactive
Output power capacity2.2 kVA
Output power1980 W
WaveformSine
Input operation voltage (min)70 V
Input operation voltage (max)153 V
Input frequency50/60 Hz
Output operation voltage (max)120 V
Output frequency50/60 Hz
Automatic Voltage Regulation (AVR)Yes
Surge energy rating540 J
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)5%
Noise level55 dB
Power protection featuresOverload
Audible alarm(s)Yes
Web-based managementYes
Audible alarm modesAlarm when on battery, Low battery alarm
Auto-restartYes
Temperature voltage compensationYes

Ports & interfaces

AC outlet typesNEMA 5-15R, NEMA 5–20R
Power plugNEMA L5-30P
AC outlets quantity8 AC outlet(s)
USB portYes
Serial interfaceYes
SmartSlotYes

Battery

Battery technologySealed Lead Acid (VRLA)
Number of batteries supported1
Battery life (max)5 year(s)
Battery recharge time3 h
Hot-swap batteryYes
Automatic battery testYes
Cold startYes

Design

Form factorRackmount/Tower
Product colourBlack
Rack capacity2U
Cable length2.44 m
Display typeLCD
LED indicatorsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Packaging content

Cables includedRS-232, USB cable
Quick installation guideYes

Certificates

Compliance certificatesRoHS
CertificationBSMI, CSA, EN 50091-2, EN 55022 Class A, , FCC Part 15 Class A, NOM, TAA, TUV, UL 1778, VCCI Class A

Sustainability

Sustainability certificatesENERGY STAR

Weight & dimensions

Width431 mm
Depth667 mm
Height85 mm
Weight38.5 kg

Packaging data

Screws includedYes
BracketYes
Resource CDYes
Software CDYes
Package width596 mm
Package depth869 mm
Package height243 mm
Package weight45.4 kg

Logistics data

Products per pallet8 pc(s)
