APC SMX2200HV + WBEXTWAR3YR-SP-04

APC SMX2200HV + WBEXTWAR3YR-SP-04

Model SMX2200HV + WBEXTWAR3YR-SP-04

44 specifications
  • Noise55 dB
  • TypeRackmount/Tower
  • Weight38.6 kg
  • ColourBlack
  • Output power capacity2.2 kVA
  • AC outlet typesC13 coupler, C19 coupler
See all specifications

Overview

Noise
55 dB
Type
Rackmount/Tower
Weight
38.6 kg
Colour
Black
Output power capacity
2.2 kVA
AC outlet types
C13 coupler, C19 coupler
Brand
APC
Model
SMX2200HV + WBEXTWAR3YR-SP-04
Part number
SMX2200HV + WBEXTWAR3YR-SP-04
Also known as
APC SMX2200HV + WBEXTWAR3YR-SP-04 uninterruptible power supply (UPS) 2.2 kVA 1980 W 10 AC outlet(s)

Specifications

44 specifications in 9 groups

Features

Output power capacity2.2 kVA
Output power1980 W
WaveformSine
Input operation voltage (min)140 V
Input operation voltage (max)280 V
Input frequency50/60 Hz
Output operation voltage (min)208 V
Output operation voltage (max)240 V
Output frequency regulation3 Hz
Automatic Voltage Regulation (AVR)Yes
Surge energy rating645 J
Efficiency98.1%
Emergency Power Off (EPO)Yes
Input current Total Harmonic Distortion (THD)5%
Noise level55 dB
Surge protectionYes
Audible alarm(s)Yes

Ports & interfaces

AC outlet typesC13 coupler, C19 coupler
Power plugC20 coupler
AC outlets quantity10 AC outlet(s)
Number of output IEC jumpers2

Battery

Battery technologySealed Lead Acid (VRLA)
Battery recharge time3 h

Design

Form factorRackmount/Tower
Product colourBlack
Rack capacity4U
Cable length1.83 m
Display typeLCD

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m

Certificates

Compliance certificatesRoHS

Weight & dimensions

Width178 mm
Depth483 mm
Height432 mm
Weight38.6 kg

Packaging data

Package width586 mm
Package depth633 mm
Package height330 mm
Package weight47.7 kg

Other features

Battery typeAPCRBC143
